CX460 CX470B Case Oil Seal LZ008350 Arm Cylinder Service Kit Replacement Kits
Price:
Negotiation
MOQ:
Trial order acceptable
Delivery Time:
3-5 days after payment received(public holiday excluded)
Brand:
SUNCAR
Product Description
CX460 CX470B Case Oil Seal LZ008350 Arm Cylinder Service Kit Replacement Kits
| Product Name | Arm Cylinder Service Kit |
| Model | CASE CX460, CX470B |
| Part Number | LZ008350 |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Place of Origin | China(Mainland) |
| Brand name | SUNCAR |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(FedEx, UPS, DHL, TNT, etc.) |
| Payment Terms | Western Union, Paypal, T/T, Transfer |
| CertifiC.A.Tion | ISO9001 |
| Warranty | Unavailable |
| Customized | OEM & ODM are welcomed |
| C.A.Tegory Group | Hydraulic cylinder seal kit |
| Condition | New, genuine new |
| Sample | Available |
| Applicable Industries |
Building Material Shops, Machinery Repair Shops, Retail, Construction work |
| Feature | High Sealing performance/ wear resistance |
| Rod | 95 MM |
| Bore | 190 MM |
| AppliC.A.Tion | Arm |
Customer Service:
- If you are interested in our products or have any questions, you can send us an email through the mail system or contact us on social media.
- Normally, the email will be replied within 24 hours; except every Sunday and holiday. When we return to the office, we will reply as soon as possible
- If you do not find the product you need, please send us an email with a picture, and we will be happy to help you.
- Positive feedback is very important to us.
Related Parts:
| Pos. | Part No | QTY | Parts name |
| . . | KTV10710 | [1] | HYDRAULIC CYLINDER |
| . . | KTV12731 | [1] | HYDRAULIC CYLINDER |
| 3 | LU002220 | [1] | CYLINDER END CAP |
| 4 | LB00460 | [1] | BUSHING |
| 5 | LA00622 | [1] | RING |
| 7 | LJ00988 | [1] | JACK PISTON |
| 8 | LE012480 | [2] | SCRAPER RING |
| 9 | LE00623 | [2] | SEALING STRIP |
| 10 | LE012420 | [1] | RING |
| 11 | LE015220 | [1] | SEALING RING |
| 12 | LE00616 | [1] | BACK-UP RING |
| 13 | LE015230 | [1] | WIPER SEAL |
| 14 | 154877A1 | [1] | O-RING |
| 15 | LE00619 | [1] | BACK-UP RING |
| 16 | 108R030W100N | [8] | BOLT |
| 17 | LE00986 | [1] | BACK-UP RING |
| 18 | LE00620 | [1] | SEAL |
| 18 | LE018360 | [1] | SEAL |
| 19 | LE00621 | [1] | RING |
| 20 | LA00910 | [1] | SPECIAL NUT |
| 21 | LA00617 | [1] | SCREW |
| 22 | LB00459 | [1] | BALL |
| 23 | LE00948 | [4] | SEAL |
| 24 | LR01136 | [1] | HYD TUBE |
| 25 | LR015640 | [1] | HYD TUBE |
| 26 | 154579A1 | [2] | O-RING |
| 27 | LA00751 | [8] | BOLT |
| 28 | LD001590 | [1] | MOUNTING CLIP |
| 28 | LD001710 | [1] | CLAMP BRACKET |
| 29 | LD00093 | [1] | CLAMP BRACKET |
| 30 | LD00094 | [1] | CLAMP BRACKET |
| 31 | LD00095 | [1] | CLAMP BRACKET |
| 32 | 828-14050 | [4] | BOLT |
| 33 | 892-16014 | [7] | LOCK WASHER |
| 34 | LS003200 | [3] | HALF-FLANGE |
| 35 | LA00616 | [3] | BOLT |
| 36 | LJ00624 | [1] | BLEEDER |
| 36A. | 154467A1 | [1] | O-RING |
| 37 | 153912A1 | [1] | LUBE NIPPLE |
| 38 | LK005150 | [2] | HALF-FLANGE |
| . . | LR00896 | [1] | HYD CYL SLEEVE |
| 41 | NSS | [1] | NOT SOLD SEPARAT |
| 42 | KTV1125 | [1] | SELF LUB RING |
| . . | LZ008360 | [1] | PISTON ROD |
| . . | LB00948 | [1] | PISTON ROD |
| 44 | NSS | [1] | NOT SOLD SEPARAT |
| 45 | KTV1125 | [1] | SELF LUB RING |
| . . | LZ008350 | [1] | SEAL KIT |
