707-99-67280 Arm Oil Seal Kit Hydraulic Cylinder For PC300-6 PC300-6Z Komatsu Excavator Service Kit
Price:
Negotiation
MOQ:
Trial order acceptable
Delivery Time:
3-5 days after payment received(public holiday excluded)
Brand:
SUNCAR
Product Description
707-99-67280 Arm Oil Seal Kit Hydraulic Cylinder For PC300-6 PC300-6Z Komatsu Excavator Service Kit
| Product Name | Arm Cylinder Oil Seal Kit |
| Part Number | 707-99-67280, 7079967280 |
| Model |
KOMATSU PC300-6, PC300-6Z, PC300LC-6, PC300LC-6Z, PC300SC-6, PC340NLC-6, PC350-6Z, PC350-6, PC350LC-6, PC350LC-6Z |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Place of Origin | China(Mainland) |
| Brand name | SUNCAR |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(FedEx, UPS, DHL, TNT, etc.) |
| Payment Terms | Western Union, Paypal, T/T, Transfer |
| CertifiC.A.Tion | ISO9001 |
| Warranty | Unavailable |
| Customized | OEM & ODM are welcomed |
| C.A.Tegory Group | Hydraulic cylinder seal kit |
| Condition | New, genuine new |
| Sample | Available |
| Applicable Industries | Building material shops, machinery repair shops, retail, construction work... |
| Feature | High sealing performance/ wear resistance |
| AppliC.A.Tion | Arm |
| Rod | 110 MM |
| Bore | 160 MM |
| Cylinder No. | 207-63-02541 |
Basic Requirements For Sealing Materials:
- The performance of the sealing material is an important factor to ensure effective sealing. The selection of the sealing material is mainly based on the working environment of the sealing element, such as the temperature, the working pressure, the working medium used, and the movement mode. The basic requirements for sealing materials are as follows:
- Have certain mechanical properties, such as tensile strength, elongation, etc.;
- Appropriate elasticity and hardness, small compression set;
- High temperature and low temperature resistance, no decomposition or softening at high temperature, and no hardening at low temperature;
- It is compatible with the working medium, without swelling, decomposition, hardening, etc.;
- Good oxygen resistance and aging resistance, durable;
- Abrasion resistance, no corrosion to metal;
- Easy to shape and process, low price.
Related Parts:
| Pos. | Part No | Product Name | Qty |
| G-1 | 207-63-X9031 | ARM CYLINDER GROUP | 1 |
| G-1 | 207-63-X9030 | ARM CYLINDER GROUP | 1 |
| G-1 | 207-63-X2521 | ARM CYLINDER GROUP | 1 |
| 207-63-02522 | ARM CYLINDER ASSEMBLY | 1 | |
| 207-63-02521 | ARM CYLINDER ASSEMBLY | 1 | |
| 1 | 207-63-63741 | • CYLINDER | 1 |
| 2 | 707-76-10130 | • BUSHING | 1 |
| 3 | 07145-00100 | • SEAL,DUST (KIT) | 2 |
| 4 | 207-63-63722 | • ROD | 1 |
| 4 | 207-63-63721 | • ROD | 1 |
| 5 | 707-76-10130 | • BUSHING | 1 |
| 6 | 07145-00100 | • SEAL,DUST (KIT) | 2 |
| 7 | 707-71-32800 | • COLLAR | 1 |
| 8 | 707-35-91640 | • RING,BACK-UP (KIT) | 2 |
| 9 | 07000-15150 | • O-RING (KIT) | 1 |
| 10 | 707-71-61111 | • PLUNGER | 1 |
| 11 | 707-71-60250 | • PLUNGER | 1 |
| 12 | 04260-00635 | • BALL | 12 |
| 13 | 707-71-91270 | • CAP | 1 |
| 14 | 07020-00900 | • FITTING,GREASE | 1 |
| 15 | 707-27-16920 | • HEAD | 1 |
| 16 | 198-63-94170 | • SEAL,DUST (KIT) | 1 |
| 17 | 07179-13126 | • RING,SNAP | 1 |
| 18 | 707-52-90850 | • BUSHING | 1 |
| 19 | 707-51-11030 | • PACKING,ROD (KIT) | 1 |
| 20 | 707-51-11630 | • RING,BUFFER (KIT) | 1 |
| 21 | 707-35-91640 | • RING,BACK-UP (KIT) | 1 |
| 22 | 07000-15150 | • O-RING (KIT) | 1 |
| 23 | 01010-82085 | • BOLT | 12 |
| 24 | 707-88-75310 | • WASHER | 12 |
| 25 | 707-36-16380 | • PISTON | 1 |
| 26 | 01310-01216 | • SCREW | 1 |
| 27 | 707-44-16180 | • RING,PISTON (KIT) | 1 |
| 28 | 707-39-16820 | • RING,WEAR (KIT) | 2 |
| 29 | 707-44-16910 | • RING | 2 |
| 30 | 07001-05100 | • RING,BACK-UP (KIT) | 2 |
| 31 | 07000-15100 | • O-RING (KIT) | 1 |
| 32 | 207-63-63771 | TUBE | 1 |
| 33 | 207-63-63180 | TUBE | 1 |
| 34 | 01435-01055 | BOLT | 8 |
| 35 | 07000-13035 | O-RING (KIT) | 2 |
| 36 | 707-88-95750 | BRACKET | 1 |
| 37 | 707-88-95740 | BAND | 1 |
| 38 | 707-88-95781 | BRACKET | 1 |
| 39 | 707-88-95770 | BAND | 1 |
| 40 | 01010-81240 | BOLT | 6 |
| 41 | 01643-51232 | WASHER | 6 |
| 42 | 07283-23442 | CLIP | 3 |
| 43 | 01643-31032 | WASHER | 6 |
| 44 | 01599-01011 | NUT | 6 |
| 45 | 07000-13032 | O-RING | 2 |
| 46 | 07378-11000 | HEAD | 2 |
| 47 | 07371-31049 | FLANGE,SPLIT | 4 |
| 48 | 07372-21035 | BOLT | 8 |
| 49 | 01643-51032 | WASHER | 8 |
| 707-99-67280 | SERVICE KIT | 1 |
