Fluid Design 600-18000gpd Commercial Reverse Osmosis Water Treatment Systems
ROS Series Commercial Reverse Osmosis Systems 600~18,000GPD
These reverse osmosis systems use the proven, reliable components and are mounted on a sturdy powder-coated
metal frame. There are numerous design details learned from years of experience that are incorporated in our water filtration systems. Our process and fluid design ensures an optimum membrane life and minimizes the membrane fouling.
Operation Specifications
Reverse osmosis systems are designed and manufactured for commercial and industrial applications. These systems have been engineered for capacities ranging from 1,200-20,000gpd for low TDS feed water design (Feed water TDS<1,500ppm).
RO water filter system 0.25tph SRO-N series 9000gpd
| Small size RO system with 4" membranes | |||||
| SRO-N series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height | |
| feed water TDS<1500ppm | (1-6 pcs) | mm | |||
| SRO-N-1500 | 1500gpd | 0.25m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-3000 | 3000gpd | 0.50m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-4500 | 4500gpd | 0.75m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*650*1650 |
| SRO-N-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*650*1650 |
|
RO water filter system 0.25tph SRO-R series 9000gpd |
|||||
| SRO-R series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height | |
| feed water TDS<1500ppm | (1-6 pcs) | mm | |||
| SRO-R-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*1650*1350 |
| SRO-R-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*1650*1350 |
| SRO-R-12000 | 12000gpd | 2.00m3/h | 3.0kw | 4040 | 850*2350*1350 |
| SRO-R-15000 | 15000gpd | 2.50m3/h | 3.0kw | 4040 | 850*2350*1350 |
| SRO-R-18000 | 18000gpd | 3.00m3/h | 3.0kw | 4040 | 850*2350*1350 |
- Wastewater,
- Hotel,
- Military,
- Hospital,
- Pharmaceutical, Mining,
- Power and energy,
- Refinery,
- Restaurants,
- Schools,
- Agriculture,
- Disaster relief
- Cartridge Filtration
- Housing---4.5’’*20’’
- Filter cartridge---4.5’’*20’’, 5micron
- Quantity--- 1 pc
- Boost Pump
- Type---Vertical multistage centrifugal
- Pump material---SS304/SS316/Carbon steel
- Connection---DIN flange
- Brand---CNP
- Benefits
- Fully equipped and customizable
- Components easily accessible
- Low operation and maintenance costs
- 1-Year limited warranty
- Membrane element and pressure vessel
- Membrane model---LP21-4040
- Membrane manufacturer---Vontron/DOW/Hydronautics/Others
- Membrane rejection---99%-99.6%
- Pressure vessel spec.---FRP, 300PSI, end port
- Pressure vessel manufacturer---ROPV/Wave Cyber/First Line/Others
