AWM 18awg PVC Insulated Copper Conductors Wires And Cables Ul 1015
▼ UL Approved PVC Insulation Electric Cable, AWM Cable ul 1015 18awg wire Cable
1. Datas
| Designation | AWG | No./Wire | Conductor Diameter | DCR @ 20℃ | Insulated Thickness | Minimum insulation thickness | Insulation Diameter | Capacity in air @ 25℃ |
| AWM 1015 | 20 | 26/0.16 | 0.93 | 34.6 | 0.76 | 0.69 | 2.60±0.15 | 12 |
| AWM 1015 | 18 | 41/0.16 | 1.18 | 21.8 | 0.76 | 0.69 | 2.80±0.15 | 15 |
| AWM 1015 | 16 | 26/0.254 | 1.49 | 13.7 | 0.76 | 0.69 | 3.10±0.15 | 21 |
| AWM 1015 | 14 | 41/0.254 | 1.86 | 8.62 | 0.76 | 0.70 | 3.50±0.15 | 27 |
| AWM 1015 | 12 | 65/0.254 | 2.34 | 5.43 | 0.76 | 0.71 | 4.00±0.15 | 37 |
| AWM 1015 | 11 | 83/0.254 | 2.67 | 4.3 | 0.76 | 0.69 | 4.30±0.15 | 43 |
| AWM 1015 | 10 | 105/0.254 | 3.1 | 3.41 | 0.76 | 0.69 | 4.60±0.20 | 50 |
| AWM 1015 | 9 | 133/0.254 | 3.81 | 2.71 | 0.76 | 0.69 | 5.35±0.20 | 63.0 |
| AWM 1015 | 8 | 168/0.254 | 4.00 | 2.14 | 1.14 | 1.04 | 6.60±0.25 | 74.7 |
| AWM 1015 | 7 | 133/0.321 | 4.83 | 1.7 | 1.14 | 1.04 | 7.20±0.25 | 85.5 |
| AWM 1015 | 6 | 266/0.254 | 5.43 | 1.35 | 1.53 | 1.37 | 8.50±0.25 | 99.0 |
| AWM 1015 | 5 | 336/0.254 | 6.09 | 1.07 | 1.53 | 1.37 | 9.20±0.25 | 117.0 |
| AWM 1015 | 4 | 420/0.254 | 6.80 | 0.85 | 1.53 | 1.37 | 10.00±0.30 | 135.0 |
| AWM 1015 | 3 | 532/0.254 | 7.10 | 0.67 | 1.53 | 1.37 | 10.50±0.30 | 153.0 |
| AWM 1015 | 2 | 665/0.254 | 8.60 | 0.53 | 1.53 | 1.37 | 11.8±0.30 | 180.0 |
| AWM 1015 | 1 | 836/0.254 | 9.60 | 0.42 | 2.1 | 1.83 | 13.50±0.40 | 207.0 |
| AWM 1015 | 1/0 | 1045/0.254 | 10.85 | 0.34 | 2.1 | 1.83 | 14.40±0.50 | 243.0 |
| AWM 1015 | 2/0 | 1330/0.254 | 12.30 | 0.266 | 2.1 | 1.83 | 16.40±0.50 | 288.0 |
2. Advantages
a. Excellent resistance to oil, corrosives, UV etc.
b. Flexible, conviniently to assemble
C. Uniform insulation thickness of wire to ensure easy stripping and cutting
3. Construction
a. Core Conductor: Stranded annealed flexible conductor
b. Popular sizes: 30AWG-4/0AWG
c. Insulation: Flame-retardant PVC
d. Temperature rating: 105℃
e. Approval: UL,ROSH
f. Voltage suitable: 600V
4. Production Application
Usually used in weak current engineering, suitable for general electronic and electrical equipment internal connection lines, wiring for lighting equipment, medical and chemical industries, etc.
▼ Packing&Delivery:
We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline
is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
The cable is supplied in wooden reels, corrugated boxes, and coils. Cable ends are sealed with BOPP self-adhesive
tape and non-hygroscopic sealing caps to protect the cable end from moisture. The required marking shall be printed
with a weather-proof material on the outsides of the drum according to customers' requirements.
