Yttria Stabilized Zirconia Ceramic Plate with Holes
Yttria Stabilized Zirconia Ceramic Plate with Holes
Description:
Zirconia ceramic parts are made of zirconium oxide ceramics which is a kind of strongest technical ceramic material with exceptional strength, high toughness, and superb reliability. These outstanding characteristics result in excellent resistance to wear and corrosion.
Ceramic plate are used in many electronic applications where a thin insulating layer of thermally stable material is required to conduct heat away from electronic components whilst electrically insulating them.
Technical Parameters:
|
Performance |
Unit |
Typical value |
|
Density |
g/cm3 |
>6.0 |
|
HV Hardness |
Kg/mm2 |
>1300 |
|
Compressive Strength |
MPa |
5500 |
|
Flexural Strength |
MPa |
1250 |
|
Modulus of Elasticity |
Gpa |
200 |
|
Thermal Conductivity |
W/(m.k) |
3(20-400℃) |
|
Thermal Expansivity Cofficient |
10^-6K^-1 |
10 |
|
Facture Toughness |
Mpa.m0.5 |
8 |
|
Grain Size |
um | 0.5 |
Principal characteristic:
1.Low thermal conductivity
2.High density
3.Chemical inertness
4.Resistance to molten metals
Application:
1. Refractories.
2. Abrasives.
3. Instrumentation.
4. Lab ware.
5. Bio-medical devices.
More pictures:
