High Speed Automatic Flexo Printing Slotting Die Cutting Machine Of Lead Edge Feeding Type
Main Performance:
Main Performance:
1. Adopt vacuum absorption, lead edge feeding paperboard, design and manufacturing, the whole operation is humanized design, can be set in a short time, modify, execute, replace, memory function, and accurate display.
2. Al transmission roller material, adopt high-quality steel, balanced correction, running smooth, surface grinding, hard chrome plating.
3. All gear drive, using high-quality alloy steel, heat treatment, grinding.
4.The oil automatic balance device, keeping each unit oil balance.
5. With automatic -returning-zero, record and memory, printing plate cleaned memory, order and dust removal, and other functions, can be selected combined with touch screen PLC control, easy operation.
6.Mesh roller:you can use Metallic or Ceramic Anilox Roller,anilox roller lines select according to user requirements.
| Model | Unit | LUM-2000 | LUM-2200 | LUM-2400 | 2600 | |||||||
|
Design Speed
|
Pcs/min | 100/150/200 | ||||||||||
| Economic Speed | Pcs/min | 70-80/100-130/150-160 | ||||||||||
| Max.feeding size | mm | 950×2000 | 950×2200 | 950×2400 | 1300×2400 | 1300×2600 | ||||||
| Min.size of paperboard | mm | 260×500 | 260×500 | 260×500 | 260×500 | 260×500 | ||||||
| Min. space of slotting | Obverse |
mm
|
160×160×160×160 | 160×160×160×160 | ||||||||
| Reverse knife |
mm
|
280×80×280×80 | 280×80×280×80 | |||||||||
| Max. depth of slot | mm | 240 | 240 | 240 | 300 | 300 | ||||||
| Skip feeding size | mm | 1100×2000 | 1100×2200 | 1100×2400 | 1500×2400 | 1500×2600 | ||||||
| Max.printing area | mm | 950×1800 | 950×2000 | 950×2200 | 1250×2200 | 1250×2400 | ||||||
| Plate Thickness | mm | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 | ||||||
