1,The maximum production width of the corrugated cardboard:1800mm
2,Design speed:100m/min
3,Economic speed:60-80m/min
note:Production line speed test paper should meet the following requirements:(the surface temperature of the equipment is not less than 172℃)
﹡Paper rating of not less than B grade ﹡Paper moisture content of about:11%±2%
﹡top paper:100-250g/m2 ﹡core paper:100--250g/m2
﹡corrugated paper:100-200g/m2
4,Flute-type combination:A ,C, B, E(as customers' requirement)
5,Steam the necessary requirements:
﹡amount of steam 2500-3000Kg/Hr ﹡the highest pressure:1.2Mpa
﹡common pressure:0.8-1.1Mpa

6,power supply:380V 50Hz Three-phase four-wire system
7,equipment installed total power:about150KW The actual power consumption:about 80KW(full speed)
8,equipment covers:about60m×10m×5m(Specific length of foundation Figure prevail)
9,Equipment out of paper orientation:According to the user to determine the transmission plant set left or right position
10,Equipment applicability,Available in A, B, C class domestic or imported paper Paper
