PSWL61.CXBXXHKAX EGA Radar VEGAPULS WL 61 Series Ideal For Water And Sewage Level Measurement
Price:
Negotiable
MOQ:
1
Delivery Time:
Negotiable
Brand:
VEGA
Product Description
PSWL61.CXBXXHKAX EGA Radar, VEGAPULS WL 61 series Ideal for water and sewage level measurement
Vega Radar Level Sensor
The Vega radar level sensor has Profibus PA, Foundation Fieldbus and 4mA to 20mA HART - two-wire output. It is an affordable and versatile radar sensor for continuous level measurement of water and sewage. It has many great features, including a measuring range of 15m. This radar sensor delivers exact measurements with an accuracy of ±2mm.
Features and Benefits
The supply voltage ranging from 9.6VDC to 36VDC
Non-contact measurement
Cable mounting
maintenance-free and does not wear
Unaffected by pressure, temperature, steam and fog
High accuracy
Exact measuring results independent of product, process and ambient conditions
High plant availability, because wear and maintenance-free
Maintenance-free operation through non-contact measuring principle
Housing protection: Plastic single chamber/IP68 (2bar)/with cable outlet
Cable material: 6m suspension cable (can be shortened) / PUR
Operating temperature ranges between -40°C and 80°C
Process fitting: compression flange from DN 80 or ANSI 3in, thread G1A, mounting strap
Deviation is ±2mm
Non-contact measurement
Cable mounting
maintenance-free and does not wear
Unaffected by pressure, temperature, steam and fog
High accuracy
Exact measuring results independent of product, process and ambient conditions
High plant availability, because wear and maintenance-free
Maintenance-free operation through non-contact measuring principle
Housing protection: Plastic single chamber/IP68 (2bar)/with cable outlet
Cable material: 6m suspension cable (can be shortened) / PUR
Operating temperature ranges between -40°C and 80°C
Process fitting: compression flange from DN 80 or ANSI 3in, thread G1A, mounting strap
Deviation is ±2mm
Applications
Its flood-proof IP68 housing ensures maintenance-free operation
The sensor is operated via the signal cable (HART, Profibus PA or FF) or via Bluetooth
Open flumes and gauge monitoring to measure level and overflow volume
Integrated Bluetooth module for wireless communication via smartphone, tablet or PC
The sensor is operated via the signal cable (HART, Profibus PA or FF) or via Bluetooth
Open flumes and gauge monitoring to measure level and overflow volume
Integrated Bluetooth module for wireless communication via smartphone, tablet or PC
Certifications
ATEX II 1G, 1/2G
2G EEx is IIC T6
IEC
FM
CSA certified
2G EEx is IIC T6
IEC
FM
CSA certified
| Device type | Radar |
| Installation type | Cable |
| level | 6m |
| Minimum temperature | -20°C |
| Maximum operating temperature | +60°C |
| current | 131 mA |
| series | VEGAPULS WL 61 |
