E+H FMR51-8ABLCABDA5AJJ+P3JAZ1 Radar measurement Time-of-Flight Micropilot FMR51

E+H FMR51-8ABLCABDA5AJJ+P3JAZ1 Radar measurement Time-of-Flight Micropilot

Specs at a glance

• Accuracy

  +/- 2 mm (0.08 in)

• Process temperature

  XT: -196...+280 °C
  (-321...+536 °F)
  HT: -196...+450 °C
  (-321...+842 °F)

• Process pressure / max. overpressure limit

  Vacuum...160 bar
  (Vacuum...2320 psi)

• Max. measurement distance

  Standard: 40 m (131 ft)
  With "Advanced dynamics": 70 m (230 ft)

• Main wetted parts

  316L, Alloy C, PTFE, ceramic

  Field of application

  Micropilot FMR51 for level measurement even under extreme process conditions like high temperature and high pressure in the oil & gas and chemical industry. The FMR51 free space radar offers maximum reliability due to an innovative and patented sensor-design. Micropilot is used for continuous, non-contact level measurement of liquids, pastes and slurries. The measurement is not affected by changing media, temperature changes, gas blankets or vapors. Remote access via SmartBlue app is available.
