26530-05-10-00-000-088-14-04-00 BENTLY NEVADA Dual Probe Transducer System
Price:
USD1990
MOQ:
1
Delivery Time:
4-6weeks
Brand:
BENTLY NEVADA
Product Description
26530 Dual Probe Transducer System
Description
The Dual Probe Transducer System consists of a proximity probe and a seismic or
Velomitor® transducer installed at approximately the same point in a common transducer
housing. This transducer system is capable of making four separate measurements:
Shaft relative radial position (displacement) relative to the probe mounting
location, measured by the proximity probe;
Shaft relative radial dynamic motion (vibration) relative to the probe
mounting location, measured by the proximity probe;
Machine casing absolute vibration measured by the seismic vibration; and
Shaft absolute motion represented by the summation of the seismic
signal (after integration to displacement) and the shaft relative
displacement.
The Dual Probe Transducer System provides the its best measurement data
when transducer housing is mounted on a portion of the bearing housing or
cover that is mechanically referenced to the bearing.
Temperature Range
3300 XL 8 mm
Probe:
-51°C to +177°C (-60°F to +351°F)
Note: Exposing the 3300 XL
probe to temperatures below -
34°C (-30°F) may cause
premature failure of the probe
pressure seal.
Spare 3300 XL 8 mm Reverse Mount Probe, 3/8-24 UNF
threads
330105-02-12-CXX-DXX-EXX
Spare 3300 XL 8 mm Reverse Mount Probe, M10 X 1
threads
330106-05-30-CXX-DXX-EXX
