High Safety Lifepo4 12v 6ah Rechargable Battery , Black Case with Custom Size
High Safety Lifepo4 12v 6ah Rechargable Battery , Black Case with Custom Size
1. OptimumNano LiFePO4 Cells List
No |
Model | Voltage(V) | Capacity (Ah) | Diameter(mm) | Height(mm) | Weight(g) |
| 1 | IFR14500 | 3.2V | 500mAh | 14 | 50(±0.5mm) | 25 |
| 2 | IFR18650 | 3.2V | 1.3Ah | 18 | 65(±0.5mm) | 45 |
| 3 | IFR26650 | 3.2V | 3Ah | 26 | 65(±0.5mm) | 85 |
| 4 | IFR32650 | 3.2V | 5Ah to 5.5Ah | 32 | 70(±0.5mm) | 145 |
| 5 | IFR32750 | 3.2V | 6Ah | 32 | 75(±0.5mm) | 160 |
2. Specification, Package and Application
No. |
Item | Data | Remark | |||||||||||||||||||
| 1 | Model | OPT-012-006 | Battery Pack | |||||||||||||||||||
| 2 | Rated Voltage/Capacity (0.2C5A) | 12V (Working Voltage) | 6Ah | |||||||||||||||||||
| 3 | Max.Charge Voltage/ Cut-off Voltage | 14.6V | 10V | |||||||||||||||||||
| 4 | Standard/Max Charge Current | 1.2 / 12A | 0.2C5A / 2C5A | |||||||||||||||||||
| 5 | Standard Charging Time | 5h | 0.2C5A | |||||||||||||||||||
| 6 | Max Continuous Discharge Current | 18 | 3C5A | |||||||||||||||||||
| 7 | Peak Discharge Current | 36A | 6C5A/10s | |||||||||||||||||||
| 8 | Impedance(Max, at 1000Hz.) | ≤ 50mΩ | ||||||||||||||||||||
| 9 |
|
|||||||||||||||||||||
10 |
Charge method (CC/CV) | Standard | 0°C~45°C | |||||||||||||||||||
| Discharge | -20°C~70°C | |||||||||||||||||||||
| Storage | -20°C~45°C | |||||||||||||||||||||
Product Feature
1. Safety: safest Li-Ion battery, CE UL approved, built-in PCM/BMS, no fire, no explosion
2. Clean and Green energy, no toxic material contained
3. Long life cycle:> 2000 times at 1C rate and 100%DoD, 6-8 times of lead acid battery
4. No memory effect, highly efficient,charge anytime
5. Small size and light weight: 1/2 size& weight of lead acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 3% monthly
Application
1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car
2. Light electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
3. E-tool: electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices, Telecom base Station
6. Small medical equipment and portable equipment
Certitication:
| CE, UL, ROHS, SGS, TS/16949 and ISO9001-2008 |
Shipping
1. We will ship the products within 15 working days after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL/TNT/EMS and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsiblility of the shipping service.
