Robot Interface RS485 28kg 48v 60ah AGV Lithium Battery

JW 48v 60ah with communication battery Lifepo4 battery for Robot AGV RV Camping Caravan UPS Storage Battery

Zhongshan Jinwo Electronic Technology Co., Ltd.

48V 60AH lithium ion battery pack for AGV, RV, Camping Caravan, UPS, Storage Battery and so on.

Battery specification

1) Rated voltage 48 V

2) Rated capacity 60 AH

3) Max charge voltage 54V ±1.0V

4) Cut off voltage 42V

5) Charge method CC&CV

6) Dimension L(525mm)*W(260mm)*H(160mm)

7) Weight ≤28 kg

8) Communication interface RS485

9) Continuous discharge current 60A

10) Discharge pulse current 100A

11) Charging temperature 0～45℃

12) Discharging temperature: -20～60 ℃

13) Storage temperature: -20～60 ℃

14)Temperature protection: 65℃±5℃

LiFePo4 battery pack Advantanges:

1) Safe:The safest Li-ion batter so far,accredited with CE and UL.

2) Environment-Friendly:Accredited with ROHS,without any hazardous and noxious substances.

3) Long cycles life:Over 2000 cycles with capacity staying at 80% min.

4) No memory effect:Always ready for charge and use,with no need to charge after a full discharge

.
5) Wide temperature range:Avaiable for use when the termperature ranges from -20-60 centigrade.
