Deep Cycle RV Lifepo4 400ah 12v Marine Battery For Trolling Motor
Lifepo4 12v 400ah Deep Cycle Battery For Lithium Ion LiFePO4 Battery For Leisure RV Trailer Boat Solar Storage Motorho
jinwo Lifepo4 12v 400ah Deep Cycle Battery For Power And Energy Storage
This 12v 400ah lithium battery is installed by high quality LiFePO4 cell 4S2P with high precision BMS protection system. The battery was used the scientific internal structure design, advanced battery production technology, with high specific energy and long life, safe and reliable, wide operating temperature range and other characteristics, is a green power supply equipment.
| Normal performance | |||
| NO | Item | General Parameter | Remark |
| 1 | Model | 3.2V 200AH CATL | Single |
| 2 | Casing material for single cell | Nickel plated steel | |
| 3 | Standard capacity(0.2C5A) | 400Ah | |
| 4 | Rated voltage | 12.8V | 3.20V(Work voltage:3.20V) |
| 5 | Max.Charge voltage | 14.6V | 3.65V(Single Ave. charge Voltage) |
| 6 | Cut-off voltage | 10V | 2.50V(Single Ave. Discharge Voltage) |
| 8 | Standard charge current | 200A | 0.5C |
| 9 | Charging Time | About 8h | |
| 10 | Max Continuous discharge current | 100A | 1C |
| 11 | Peak discharge current | 200A | 0.5C 5 seconds |
| 12 | Battery dimension | customized | |
| 13 | (Approx.)Total weight(Approx.) | About 45kg | |
| 14 | (Max, at 1000Hz.)Impedance(Max, at 1000Hz.) | ≤ 45mΩ | |
| 15 | (CC/CV)
Charge method (CC/CV) |
Standard | 0℃~45℃ |
| discharge | -20℃~45℃ | ||
| storage | -20℃~45℃ | ||
*Battery capacity, dimension and shape can be customized as you require
Features of our lifepo4 battery pack
- More than 3000 times cycle life.
- Bulit in BMS protection
- High discharge rate.Max discharge current 175A,up to 320A.
- Can be connected in series and parallel
- Maintenance free
- Have passed different tests.No explosion,no smoke,no leakage.
- Bluetooth function can be added to read battery status
- 3 years manufacturer's warranty.
- Over Current and Over Voltage
- Over Charge and Over Discharge
- Thermal Protection
- Over Load
Widely used in RV, camping car, marine,boat,golf carts,sightseeing cars,solar backup,solar pv light, industrial equipment, and other deep cycle replacement.
