10 Years Lifespan 5120Wh 48 Volt 100ah Lithium Battery
Price:
Negotiable
MOQ:
10
Delivery Time:
18-25 days
Brand:
JINWO
Product Description
Hot seller Telecom/UPS/Solar 48V 100Ah LiFePO4 Rechargeable Battery with 10 years lifespan
JINWO is a lithium battery Manufacturer for over 16years, recognized by customers from Australia,Europe and North America.We offer Top quality with competitive price for lithium lifepo4 batteries cells! All our batteries is 10years Warranty. Looking for distributors!
| Items | Parameter |
| Battery Type | LiFePO4 |
| Nominal Voltage | 48V |
| Nominal Capacity | 100Ah |
| Energy | 5120Wh |
| Internal Resistance | ≤15mΩ |
| Limited Charge Voltage | 58.4±0.2V |
| Floating Charge Voltage | 54±0.2V |
| Charge Method | CC/CV |
| Discharge Cut-off Voltage | 40.0V |
| Charge Current | 100A (Customizable) |
| Continuous Discharge Current | 100A (Customizable) |
| Pulse Discharge Current | 200A (Peak) |
| Depth of Discharge | 100%DOD (adjustable) |
| Reserve Minutes @ 20A | 300 min |
| Reserve Minutes @ 50A | 120 min |
| Cycle Life | > 6000 cycles |
| Communication functions | Bluetooth/RS485 Optional |
| Built in Automatic Battery Protection System | Internal |
| Automatic Short Circuit Protection | Instant |
| Automatic Reverse Polarity Protection | Instant |
| Internal Cell Thermal Safety Fuse | Yes |
| Flame Retardant Electrolyte | Yes |
| Length Way Circuit Boards | Yes |
| Automatic Internal Cell Balancing | Yes |
| Automatic Fault Recovery | Yes |
| Explosion Proof Stainless Steel Cells | Yes |
| Dimension | 5U |
| Weight | 46Kg |
| Charge Temperature Range | 0~65℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
| Self-Discharge Rate (Residual capacity) | 1.5%/years |
| Series Connection | Customized |
| Paralell Connection | Up to 16S |
| Warranty | 10Years |
| Features : | |
| 1: Long cycle life -product life expectancy of 15 - 20 years | |
| 2: Modular system allows storage capacity to be easily expandable as power needs increase | |
| 3: Proprietary architecture and integrated Battery Management System (BMS) - no additional programming, firmware, or wiring | |
| 4: Operates at unparalleled 98% efficiency for more than 5,000 cycles | |
| 5: Can be rack mounted or wall mounted in a dead space area of your home/business | |
| 6: Offers up to 100% depth of discharge | |
| 7: Non-toxic and non-hazardous recylcable materials - recycle at end of life | |
| Model | LFP50-48 | LFP100-48 | LFP200-48 |
| Nominal Voltage(V) | 48 | 48 | 48 |
| Nominal Capacity(Ah) | 50 | 100 | 200 |
| Usable Capacity(Wh) | 2400 | 4800 | 9600 |
| Dimension(mm) | customizabl | 442*410*220
customizabl |
442*450*250
customizabl |
| Weight(Kg) | 29 | 44 | 86 |
| Cycle Life | 4000~6000,25℃ | 4000~6000,25℃ | 4000~6000,25℃ |
| Communication Port | RS232,RS485,CAN | RS232,RS485,CAN | RS232,RS485,CAN |
| Working Temperature ℃ | 0~55 | 0~55 | 0~55 |
| Discharge Voltage (V) | 39~40.5 | 40.5~42.5 | 40.5~42.5 |
| Charge Voltage(V) | 53.2~54 | 53.2~54 | 53.4~54 |
| Internal Impedance(mΩ) | ≥50 | ≥50 | ≥50 |
| Charge / Discharge Current (A) | 10(Recommended) | 20(Recommended) | 40(Recommended) |
| 50(MAX) | 100(MAX) | 100(MAX) | |
| Design Life(Years) | 12 | 12 | 12 |
