332/F9032 Genuine Parker / JCB 3CX Twin Hydraulic Pump 37 + 37 CC/REV Replacement
332/F9032 Genuine Parker / JCB 3CX Twin Hydraulic Pump 37 + 37 CC/REV replacement
Elephant Fluid Power makes 332/F9032 Genuine Parker / JCB 3CX Twin Hydraulic Pump 37 + 37 CC/REV replacement,equivalent quality as original,competitive price,fast lead time,one year warranty since sales.
- Rotation: Clockwise (looking from shaft end)
- 1” Diameter 15 tooth SAE splined shaft 16/32 Pitch
- SAE B 2 hole mounting flange
- Front pump displacement: 37 cc/rev (37L/Min per 1000 rpm)
- Rear pump displacement: 37 cc/rev (37L/Min per 1000 rpm)
- Single 2” SAE flange inlet
- Front pump outlet: 1 1/16”-12 UNF threaded
- Rear pump outlet: 1 1/16”-12 UNF threaded
- Max. Input shaft torque: 460 Nm
Replaces the following JCB part numbers
- 332/F9032 7029120052 7029120055 20/925744
JCB pumps we supply:
| 332/F9030 | 20/925580 | 20/903300 4074 |
| 333/G5390 | 20/925579 | 20/925592 |
| 332/F9029 | 20/925339 | 20/925357 |
| 332/G7135 | 20/925338 | 20/925732 |
| 332/F9032 | 20/925581 | 20/925588 |
| 332/F9031 | 20/925340 | 20/925356 |
| 333/G5391 | 20/925341 | 20/925591 |
| 220/925586 | 20/925366 | 20/918300 |
| 333/C5234 | 20/925337 | 20/903000 |
| 333/G5392 | 20/925578 | 7029120047 |
| 332/F9028 | 20/925586 | 7029120005 |
| 332/E6671 | 20/912800 | 7049520006 |
| 919/75002 | 20/903100 | 7049532007 |
| 20/911200 | 20/902900 | 7029530002 |
| 20/902900 | 20/903200 |
Our product range
| Hydraulic pump parts | Cylinder block | Press pin |
| Piston motor | Piston shoe | Snap ring |
| Piston pump | Retainer plate | Coil spring |
| Gear pump | Ball guide | Disk spring |
| Charge pump | Valve plate | Barrel washer |
| Pilot pump | Shoe plate | Oil seal |
| Vane pump | Bearing plate | Friction plate |
| Repair OEM parts | Swash plate | Steel plate |
| Motor spare parts | Drive shaft | Hydraulic pump parts |
