Parker F12 Hydraulic Piston Motor 30 cm3/rev 420 Bar OEM Replacement
Price:
Elephant Fluid Power
MOQ:
1 Set
Delivery Time:
5-8 days
Brand:
Elephant Fluid Power
Product Description
OEM Quality Parker Motor F12 030 060 080 090 150 Parker Hydraulic Piston Motor Replacement
Elephant OEM Quality Parker Motor F12 030 060 080 090 150 Parker Hydraulic Piston Motor Replacement offers excellent quality, competitive pricing, fast lead times, and reliable after-sales services.
Technical Specifications
- Hydraulic Piston Motor fixed displacement for high-demand applications
- Displacement: 30.0 cm³/rev
- Shaft type: Cylindrical shaft 30 mm diameter with 8 mm key width
- Flange type: ISO flange with 4 holes and centering diameter 100 mm
- Ports A and B: Flanges type SAE 6000
- Drain port: M18x1.5
- Rotation: Bidirectional
- Max speed: 6700 rpm (intermittent operation: 7300 rpm)
- Minimum rotation speed: 50 rpm
- Max working pressure: 420 bar (intermittent operation: 480 bar)
- Max oil flow: 201 liters/minute (intermittent operation: 219 liters/minute)
- Torque at 100 bar: 47.6 Nm
- Shaft seal material: Type V
- Intermittent working value allowed for maximum 6 seconds per minute
- Check specific conditions for operating as hydraulic pump
About Elephant Fluid Power Co., Ltd
We are a professional manufacturer of hydraulic pumps, motors, and pump parts. Our products are widely used in agriculture, construction, and industrial applications. We maintain an excellent reputation based on quality and service.
Our Main Product Models
| Rexroth | A2F12/23/28/55/80/107/160/200/225/250/335/500 |
|---|---|
| A2FO10/12/16/23/28/32/45/56/63/80/90/107/125/160/180/200/250/500 | |
| A7V28/55/80/107/160/225/250/355/500/1000 | |
| A6VM(A7VO)/12/28/55/80/107/160/200/250/355/500 | |
| A4VSO45/71/125/180/250/500/1000 | |
| A4V40/56/71 | |
| A4VG28/40/45/50/56/71/90/125/140/180/250 | |
| A4VTG71/90 | |
| A10VSO10/16/18/28/45/63/71/85/100/140 | |
| A10VG18/28/45/63 | |
| A11VO60/75/95/130/145/160/190/250/260 | |
| Kawasaki | K3SP36C |
| K3V63DT/112DT/140DT/180DT/280DT | |
| K3VL28/45/60/80/112/140/200 | |
| K3VG63/112/180/280 | |
| K7V63/100 | |
| K7VG180/265 | |
| K5V80/140/160/200 | |
| NV45/50/60/64/70/80/84/90/111/120/137/172/210/237/270 | |
| NX15 | |
| NVK45 | |
| KVC925/930/932 | |
| M2X55/63/96/120/128/146/150/170/210 | |
| M5X130/150/173/180/500 | |
| MX50/80/150/173/200/250/450/500/530/750 | |
| KAYABA | MAG150/170 |
| KYB87 | |
| MSG18P/27P/44P/50P | |
| MSF series | |
| Komatsu | HPV 35/55/90/160(PC60/120/200/220/300-3/5)PC400/PC650 |
| Liebherr | LPVD 35/45/64/75/90/100/125/140/165/225/250 |
| FMV075/100 | |
| LMF(V)45/64/75/90/100/125/140 | |
| Toshiba | PVB80/92 |
| PVC80/90 | |
| SG 015/02/025/04/08/12/15/17/20/25 | |
| Linder | HPV55/75/105/135/165/210/280 |
| HPR75/90/100/130/160 | |
| MPR28/45/63/71 | |
| HMR75/105/135/165 | |
| HMF28/35/50/ | |
| BPV35/50/70/100/200 | |
| B2PV35/50/75/105/140/186 | |
| BMF35/55/75/105/140/186/260 | |
| BMV35/55/75/105/135 | |
| BPR55/75/105/140/186/260 | |
| Sauer | PV90R(L)(M)030/42/55/75/100/130/180/250 |
| PV42-28/41/51 | |
| SPV15/18 | |
| KRR(LRR)025C/030D/038C/045D | |
| MR(MS)070/089/227/334 | |
| Eaton | 3321/3331 |
| 4621/4631 | |
| 5421/5431 | |
| 78461/78462 | |
| Vicker | PVE12/21/45 |
| TA19/MFE19 | |
| PVM 018/020/045/050/057/063/074/081/098/106/131/141 | |
| PVH 57/74/98/131/141 | |
| PVB 5/6/10/15/20/29/45/90 | |
| Yuken | A10/16/22/37/40/45/56/70/90/100/125/145/220 |
| A3H16/37/56/71/100/145/180 | |
| Parker | PVP16/23/33/41/48/60/76/100/140 |
| PV 016/020/023/028/032/040/046/063/080/092/140/180/270 | |
| P2/3-060/075/105/145 | |
| PAVC 33/38/65/100 | |
| Hitachi | HPV050/102/105/118/135 |
| HMGC16/32/48 | |
| HMGF35/36/38/57 | |
| Tokiwa | MKV23/33 |
| Uchida | A10VD17/23/28/40/43/71 |
| AP2D12/14/18/21/25/28/36/38/42 | |
| A8VO55/59/80/86/107/115/172 | |
| Nachi | YC35-6 |
| PVD-2B-32/34/36/38/40/42/45/50 | |
| PVD-3B-54/56/60/66 | |
| PZ-6B-180/220 | |
| PVK-2B-50/505 | |
| PZ-4B-100 | |
| PVD-00B-14/16P | |
| PVD-1B-23/28/32/34 | |
| Hawe | V30D95/140/250 |
| V60 | |
| Italy Sam | HCV50/70/90/100/125 |
| H1V55/75/108/160/226 | |
| H2V55/75/108/160/226 | |
| H1C55/75/108/1 |
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are a factory.
Q: How long is your delivery time?
A: Generally 5-10 days if goods are in stock, or 15-20 days if not in stock, depending on quantity.
Q: Do you provide samples? Are they free or extra?
A: We cannot offer free samples but can supply goods at sample prices.
Q: What are your payment terms?
A: For payments ≤1000USD: 100% in advance. For payments ≥1000USD: 30% T/T in advance, balance before shipment.
For any other questions, please feel free to contact us. We look forward to working with you.
