ADSS G652D 200m 300m 500m Communication Aramid Yarn Fiber Optic Cable
Aramid Yarn Fiber Optic Cable Span 200m 300m 500m ODM OEM Adss Fiber Optic Cable G.652D Aerial Communication Cable
Product Description:
ADSS armored fiber optic cables feature loose tube wrapped with a layer of PSP longitudinally, excellent crush-resistant performance. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight.The cable is completed with a single polyethylene (PE) sheath. It's suitable for installation in aerial or duct environment for communication between bureaus, metropolitan network, access network and is especially suitable for high-density fibers is expected.
Characteristics:
|
Cable Type
|
Fibre Opitc Cable
|
Fiber Count
|
4~288 cores
|
|
Construction
|
Stranded Loose Tube
|
Fiber Type
|
Singlemode G.652D
|
|
Inner/Outer Jacket Material
|
PE
|
Jacket Color
|
Black
|
|
Cable Diameter
|
14.0mm
|
Weight
|
155kg/km
|
|
Strength Member
|
FRP
|
Span
|
100m
|
|
Rated Tensile Strength
|
34KN
|
Modulus of Elasticity
|
12.5KN/mm2
|
