Stainless Needle Valve 6000 Psi 1/4 inch Control Instrumentation Needle Valve
Stainless steel 316 6000 Psi 1/4 inch Flow Control Instrumentation Needle Valve
| 1.Material : | SS304, SS316,SS304L,SS316L,SS410,SS416.etc. |
| 2.Size: | 1/2" NPT Stainless Steel Hydraulic Flow Control Gas Needle Valve |
| 3.Pressure Rating: | 6000PSI |
| 4.Logo: | Roke ,required logo is available |
| 5.MOQ: | 10pcs |
| 6.Samples Time: | (1)3-5days-If you want to customize your product and logo. |
| (2)1day-For our existing samples for reference. | |
| 7.OEM Accepted | Yes |
| 8.Certification available: | Yes |
| 9.Packing Details: | 1. wooden box, 38*27*17CM; 2. carton: 21*16*14CM/31*21*16CM. 3. as your request. |
| 10.Production Capacity: | 30,000pcs Per month. |
| 11.Payment Term: | (1) L/C,T/T,D/P,D/A,PAYPAL,WESTERN UNION,MONEY GRAM |
| (2) We also can provide a monthly statement payment services |
Stainless Steel Needle Valve
1. Material:stainless steel 316,304
2. Nominal pressure: 6000 PSI
3. Applicable temperature:150--230oC
4. Size:1/8"--2"
5. Applicable medium:oil,gas,water or other medium
6. Technics: forged
7. Place of origin: Shanghai,China(Mainland)
8. Specified specification available upon request.
9. OEM orders are welcomed.
| Flow Direction | Unidirection |
| Application | Industrial Usage |
| Transport Package | 1. Wooden Box, 38*27*17cm; 2. Carton: 21*16*14cm |
| Sealing Form | Gasket |
| Standard | ANSI |
| Trademark | ROKE |
| Origin | Shanghai China |
| Type | Stainless Steel Needle Valve |
| Size Range | 1/8" to 3/4" |
| Material | 316 Stainless Steel |
| Number of Ways | 2 Way |
| Working Temperature | -65℉~6000℉ (-53℃~648℃) |
| Connection | Double Ferrule |
| Woking Pressure | 10000PSI (689bar) |
| OEM service | Available |
| Media | Water, Oil, Gas and Alkaline or Acidic Liquid |
| Usage | Petroleum, Chemical, Power, Electronics, Machinery, Shipbuilding, etc |
| Type | Conn./Size | Orifice | Dimensions(mm) | ||||||
| Inlet/Outiet | In. | A | B | C | D | E | F | ||
|
|
|
1/8'' | 0.08 | 59.8 | 29.9 | 72.7 | 36 | 24.2 | 11.5 |
| 1/4'' | 0.18 | 61.7 | 30.9 | 72.7 | 36 | 24.2 | 11.5 | ||
| 3/8'' | 0.24 | 67.5 | 33.8 | 86.5 | 50 | 28.4 | 13.0 | ||
| 1/2'' | 0.24 | 71.8 | 35.9 | 86.5 | 50 | 28.4 | 11.0 | ||
|
|
4mm | 0.08 | 60.2 | 30.1 | 72.7 | 36 | 24.2 | 11.5 | |
| 6mm | 0.18 | 61.1 | 30.6 | 72.7 | 36 | 24.2 | 11.5 | ||
| 8mm | 0.18 | 63.7 | 31.9 | 72.7 | 36 | 24.2 | 11.5 | ||
| 10mm | 0.24 | 67.8 | 33.9 | 86.5 | 50 | 28.4 | 13.0 | ||
| 12mm | 0.24 | 71.4 | 35.7 | 86.5 | 50 | 28.4 | 13.0 | ||
|
|
|
1/8'' | 0.16 | 46.0 | 23.0 | 72.7 | 36 | 24.2 | 11.5 |
| 1/4'' | 0.16 | 50.0 | 25.0 | 72.7 | 36 | 24.2 | 11.5 | ||
| 3/8'' | 0.24 | 56.0 | 28.0 | 86.5 | 50 | 28.4 | 13.0 | ||
|
|
|
1/8'' | 0.16 | 46.0 | 23.0 | 72.7 | 36 | 24.2 | 11.5 |
| 1/4'' | 0.16 | 46.0 | 23.0 | 72.7 | 36 | 24.2 | 11.5 | ||
| 3/8'' | 0.24 | 52.0 | 23.0 | 86.5 | 50 | 28.4 | 13.0 | ||
Quality Assurance: Within one year after buying our products, if any quality problem that verified to be our responsibility, we will replace the defective products
Product Name : Needle Valve
Features:
1. Manufacture Standard: ASME B16.34-2004
2. Mode of Connection: female thread connector(NPT,G,Rc,Rp…)
3. Characteristic: awl seals
4. Test & Inspection: API 598-1996
5. Nominal Pressure:≤10000Psi
6. Applicable temperature:-29℃～+538℃
7. Applicable medium: water,steam,oil and corrosive media…
8. Nominal Bore Size: DN6,DN10,DN15,DN20,DN25…
