Pneumatic Knife Gate Valve DIN F4 Metal Seat For DHPE Pipe
Price:
1-100
MOQ:
1pc
Delivery Time:
2-3days
Brand:
TOBO
Product Description
DIN F4 Metal Seat Pneumatic Knife Gate Valve With Prices For Dhpe Pipe
|
Main parts and materials
|
||
|
NO.
|
Main parts
|
Materials
|
|
1
|
Valve body
|
Carbon steel/Stainless steel
|
|
2
|
Bonnet
|
Carbon steel/Stainless steel
|
|
3
|
Disc
|
Stainless steel
|
|
4
|
Stem
|
Stainless steel
|
|
5
|
Sealing surface
|
F4/Stainless steel/Hard alloy
|
|
Function and specification
|
|||||
|
Type
|
PN(MPa)
|
Testing pressure(MPa)
|
Suitable temperature(℃)
|
Suitable medium
|
|
|
Strength(water)
|
Enclose(water)
|
||||
|
PZ73W/H/Y-10C/P
|
1.0
|
1.5
|
1.1
|
≤120
|
Paper pulp, coal-slurry,sewage,dust mixture of water,ash residue.
|
|
PZ73W/H/Y-16C/P
|
1.6
|
2.4
|
1.8
|
||
|
Outline and connecting measurement
|
|||||||
|
Type
|
DN(mm)
|
Measurement(mm)
|
Reference weight(kg)
|
||||
|
L
|
D1
|
D2
|
H
|
D0
|
|||
|
PZ73W/H/Y-10C/P
|
50
|
48
|
125
|
100
|
285
|
180
|
8
|
|
65
|
48
|
145
|
120
|
298
|
180
|
10
|
|
|
80
|
50
|
160
|
135
|
315
|
220
|
12
|
|
|
100
|
50
|
180
|
155
|
365
|
220
|
14
|
|
|
150
|
57
|
240
|
210
|
475
|
280
|
29
|
|
|
200
|
70
|
295
|
265
|
540
|
360
|
38
|
|
|
250
|
70
|
350
|
320
|
630
|
360
|
66
|
|
|
300
|
76
|
400
|
368
|
780
|
400
|
100
|
|
|
350
|
76
|
460
|
428
|
885
|
400
|
119
|
|
|
400
|
89
|
515
|
482
|
990
|
400
|
195
|
|
|
450
|
89
|
565
|
532
|
1100
|
530
|
285
|
|
|
500
|
114
|
620
|
585
|
1200
|
530
|
389
|
|
|
600
|
114
|
725
|
685
|
1450
|
600
|
529
|
|
|
PZ73W/H/Y-16C/P
|
50
|
48
|
125
|
99
|
285
|
180
|
8.5
|
|
65
|
48
|
145
|
118
|
295
|
180
|
10.7
|
|
|
80
|
50
|
160
|
132
|
315
|
220
|
13
|
|
|
100
|
50
|
180
|
156
|
365
|
220
|
15
|
|
|
150
|
57
|
240
|
211
|
475
|
280
|
31
|
|
|
200
|
70
|
295
|
266
|
540
|
360
|
40.7
|
|
|
250
|
70
|
355
|
319
|
630
|
360
|
70
|
|
|
300
|
76
|
410
|
370
|
780
|
400
|
107
|
|
|
350
|
76
|
470
|
429
|
885
|
400
|
129
|
|
|
400
|
89
|
525
|
480
|
990
|
400
|
215
|
|
|
450
|
89
|
585
|
548
|
1100
|
530
|
305
|
|
|
500
|
114
|
650
|
609
|
1200
|
530
|
410
|
|
|
600
|
114
|
775
|
720
|
1450
|
600
|
550
|
|
Product Description
Main Feature
This valve is widely applied to pipelines such as water supply and drainage, construction, oil, chemical industry, natural gas, medicine, power plant, nuclear power plant and urban pollution discharge etc for purpose of adjusting or cutting the flow contains various medium, such as thick granule, sticky liquid and floating contamination ect.
|
Product Name
|
Material
|
|
Valve Body
|
Ductile iron, Carbon steel, Stainless steel
|
|
Knife
|
Stainless steel
|
|
Stem
|
Stainless steel
|
|
Handwheel
|
Cast iron
|
|
Sealing
|
NBR/EPDM/PTFE or Metal Seat
|
Gate valve
The gate valve is an elastic-seat,divided into(by forms) gate valve with scale display, rising-stem gate valve, signal gate valve, groove-type gate valve, it streesses on every detail of the design. it has built-in safety system, its disc is wholly covered and vulcanized by EPDM synthetic rubber, the valve has outstanding serviceability because of the compressive resilience of rubber,dual layer bonding/vulcanizing process and solid disc structure. The remarkable reliabiliy of the valve owes to the triply safe sealing system of the valve spindle, super strong valve spindle and comprehesive corrosin resistance, it is especially suitable for the pipelines in automatic sprinkler system and fire hydrant system , or can be used as ideal cutoff device for the pipelines in water supply/drainage , petroleum and chemical industries.
