Flange Type 14 Inch Gate Valve DN350 PN 10 14" Stainless Steel CF8 CF8M
Price:
1-100
MOQ:
1pc
Delivery Time:
2-3days
Brand:
TOBO
Product Description
14" Stainless Steel CF8 CF8M Flange Type Knife Gate Valve DN350 PN 10
|
Stainless steel flanged knife gate valve specification:
|
|||
|
Valve body
|
Stainless steel CF8, CF8M
|
||
|
Seat
|
PTFE, NBR, EPDM
|
||
|
Disc
|
Stainless steel flanged knife gate
|
||
|
Stem
|
Stainless steel flanged knife gate
|
||
|
Stainless steel flanged knife gate valve specification:
|
|||
|
1
|
Nominal pressure: 1.0MPa
|
||
|
2
|
Working medium: Cement slurry, sand pulp, fiber pulp and other media containing impurities in pipelines
|
||
|
3
|
Working temperature: ≤ 1000℃.
|
||
|
Stainless steel flanged knife gate valve features:
|
|||
|
1
|
Knife gate valve with lift type sealing surface of gate valve is adopted to strike off the adhesion on the surface and automatically clean the sundries.
|
||
|
2
|
Knife gate valve with stainless steel gate plate can prevent sealing leakage caused by corrosion;
|
||
|
3
|
Knife gate valve with hard alloy metal sealing surface can ensure the sealing and wear-proof performance and requirement;
|
||
|
Main parts and materials
|
||
|
NO.
|
Main parts
|
Materials
|
|
1
|
Valve body
|
Carbon steel/Stainless steel
|
|
2
|
Bonnet
|
Carbon steel/Stainless steel
|
|
3
|
Disc
|
Stainless steel
|
|
4
|
Stem
|
Stainless steel
|
|
5
|
Sealing surface
|
F4/Stainless steel/Hard alloy
|
|
Function and specification
|
|||||
|
Type
|
PN(MPa)
|
Testing pressure(MPa)
|
Suitable temperature(℃)
|
Suitable medium
|
|
|
Strength(water)
|
Enclose(water)
|
||||
|
PZ73W/H/Y-10C/P
|
1.0
|
1.5
|
1.1
|
≤120
|
Paper pulp, coal-slurry,sewage,dust mixture of water,ash residue.
|
|
PZ73W/H/Y-16C/P
|
1.6
|
2.4
|
1.8
|
||
Product Description
Main Feature:
This valve is widely applied to pipelines such as water supply and drainage, construction, oil, chemical industry, natural gas, medicine, power plant, nuclear power plant and urban pollution discharge etc for purpose of adjusting or cutting the flow contains various medium, such as thick granule, sticky liquid and floating contamination ect.
|
Product Name
|
Material
|
|
Valve Body
|
Ductile iron, Carbon steel, Stainless steel
|
|
Knife
|
Stainless steel
|
|
Stem
|
Stainless steel
|
|
Handwheel
|
Cast iron
|
|
Sealing
|
NBR/EPDM/PTFE or Metal Seat
|
| Technical Date | Material Specification | ||
| Nominal Diameter | DN50-600mm | Valve Body | WCB/stainless steel |
| Nominal Pressure | PN10/PN16 |
Hand Bar |
Cast Iron or Ductile Iron or Stainless Steel |
| Operation Temperature | -40°C~225°C | ||
| Power | Manual | Seal Material | EPDM OR NBR |
| Suface Treatment | Painting |
Valve Stem |
Carbon Steel |
| Application |
Portable water, water distribution service & feed lines, sewage disposol, irrigation, fire protection pipe systerm, etc. |
||
