GB10485-89 ISO Climatic Chamber Manufacturer Salt Spray Corrosion Test Chamber Machine
GB10485-89 ISO Climatic Chamber Manufacturer Salt Spray Corrosion Test Chamber Machine
Description:
Salt spray corrosion test chamber is used surface treatment of various material including mechanical, national defense, light industry, electronic, instruments etc. after these anti-corrosive treatment to test the corrosion resistance of their products.
This tester can be used to execute solution as NSS (Neutral Salt Spray), as well as ASS (Acetic acid Salt Spray).
The products comply with :CNS, ASTM, JIS, ISO standard saltwater spray test is aimed at the surface of various materials by coating, electroplating, anode treatment, corrosion prevention oil and other anti-corrosion treatment, test the corrosion resistance of its products.
Feature:
Rotating rain and spray nozzles designed to JIS specifications
Speed control for the rotating spray nozzles
Stationary product shelf - A rotating shelf is optional: see options
Water pressure regulators, gauges and flow meters
Special high-volume floor drain system to rapidly drain water out of the chamber
Interior chamber size is the smallest possible area using the JIS specified nozzles
Standard:
1.GB10485-89
2.GB4208-93
3.GB/T4942
4.Corresponding IEC ISO & ASTM standards
Model |
B-SST-60 | B-SST-90 | B-SST-120 | B-SST-160 | B-SST-200 | |
| Internal Dim(W*H*D) | 60x45x40 | 90x60x50 | 120x100x50 | 160x100x50 | 200x100x50 | |
| External Dim(W*H*D) | 108x63x119 | 140x80x139 | 178x120x149 | 230x130x149 | 270x130x159 | |
| Cabinet Material | Corrosion-resistant polymer material | |||||
| Laboratory temperature (℃) | A:25℃~70℃ B:0℃-70℃ C:-20℃-70℃ D:-40℃-70℃ | |||||
| Saturated air barrel temperature(℃) | 35±1℃50±1℃ Saline test method:35±1℃/Corrosion test method:50±1℃ |
|||||
| Saturated air pressure (kg/c㎡) | 0.8-2.0±0.01 | |||||
| (ml／80c㎡.h) Salt spray sedimentation rate (ml/80c㎡.h) |
1-2ml/80 cm2.h(Controllable) | |||||
| PH value | Salt water test method:6.5～7.2／Test method for corrosion resistance:3.0-3.2 Saline test method:6.5-7.2/Corrosion test method:3.0-3.2 |
|||||
| Power Source | AC:220V 50Hz/AC:380V 60Hz | |||||
Our Company:
1. How to choose the most suitable Mechanical Equipment ?
Our professional team will give you the best suggestion as long as you tell us what kind of test you need to do andthe required specification.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15~20 working days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
3. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
4. Can we visit your factory before order?
Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange hotel and pick up you from airport.
