Stainless Steel Simulated Rain Environment Test Chamber Ipx56 Waterproof Test Chamber For Electronic Test

Price Negotiable
MOQ: 1set
Delivery Time: 5-25 days
Brand: BOTO
Product Description
Product Paramenters
Item
Specification
Internal chamber size
800Wx800Dx800Hmm
External chamber size
1200Wx900Dx3300Hmm
IP Code
IPX5
IPX6
Internal diameter of spray nozzle
6.3mm
12.5mm
Delivery rate
12.5l/min±5%
100l/min±5%
Core of the substantial stream
Circle of approximately 40mm diameter at 2.5m distance from nozzle
Circle of approximately 120mm diameter at 2.5m distance from nozzle
Chamber material
Internal: SUS304 stainless steel, external: stainless steel
Test duration per square meter of enclosure surface area likely to be sprayed
1 min
Minimum test duration
3 min
Controller
PLC touch screen
Turntable
Diameter 300mm, rotate speed 3±1R/min
Distance from nozzle to enclosure surface
Between 2.5m and 3m
Distance from nozzle to specimen surface
200mm
Chamber material
Stainless steel, with observation window
Safety protection device
Short circuit protection, grounding protection, water shortage protection, audible and visual alarm





Details Images
Application
Vehicle
Electronic
Parts
Plastic
Foods
Chemistry
