High Altitude Low Pressure Simulation Test Chamber Climate Chamber With Humidity Control

Price Negotiable
MOQ: 1set
Delivery Time: 5-25 days
Brand: BOTO
Product Description

High Altitude Low Pressure Simulation Test Chamber Climate Chamber With Humidity Control



Products Description





High altitude low pressure simulation test
chamber can combine temperature and altitude environment with optional humidity for simultaneous environmental testing. It’s used in aerospace,communications,
information,electronics,electrical and so on.
This combination of elements allows precise
simulation of real-life condition a product might encounter at various altitude levels.
Details Images



Programmable Control System




Circuit Board




Test hole




Observation Window

Product Paramenters
Item
Specification
Internal dimension (W*D*H)
600*600*600mm
Internal material
#304 stainless steel, mirror finished
External material
Stainless steel with paint spray
Temperature range
-40~+100℃
Temperature fluctuation
±0.5℃
Temperature uniformity
±2℃
Cooling speed
1℃/min in average (without loading)
Heating speed
3℃/min in average (without loading)
Humidity
20 to 98% RH, without loading
(temperature from +20℃ to +85℃)
Humidity fluctuation
±2.5%
Humidity uniformity
±3%
Controller
TATO PLC touch screen controller,
With RS232 and USB port, APP remote control function
Vacuum range
Ordinary pressure ~ 1Kpa
Pressure fluctuation
±5%
Decompression time
≤10min
