Six Cylinder Turbocharged 38T SK380D Used Kobelco Excavator
38T Kobelco SK380 Mine Used Excavator 35T Power Parameters Machines Properties Manufactor Six Cylinder Turbocharged engine
Sk380d mine excavator is designed with high strength and high durability, super large bucket capacity, excellent excavation efficiency and ultra-low operation fuel consumption.
As the main 40t mining machine of SG, sk380d-8 is realizing the ultimate goal of "bigger, faster and more revenue" for excavators by the majority of mine customers. Therefore, sk380d-8 mining excavators of SG are more concerned and favored by customers.
The sk380d-8 mine excavator of Shengang adopts the world's most advanced Hino jo8e six cylinder turbocharged engine. Engine horsepower up to 209kw (284ps), super power, fuel saving and environmental protection. The maximum bucket capacity can reach 2.1 m3 (the largest bucket capacity in the same class). Shengang sk380d-8 mine excavator is a perfect benchmark product of 40 ton excavator.
New engine
1. The exhaust emission of engine reaches Euro 3 standard
A variety of advanced technology crystallization new engine, to minimize the particulate matter, nitrogen oxides, black smoke emissions. Strictly abide by the exhaust emission regulations implemented in Europe, the United States and Japan.
2. Standard configuration engine idling automatic function
Eliminate idling phenomenon in standby, reduce fuel consumption and exhaust emission. Because the engine stops and the timer stops, the asset value of the equipment is maintained.
3. Automatic idle function to reduce engine speed
When the operating handle is neutral, it will automatically reduce the engine speed, reduce unnecessary fuel consumption, reduce noise and exhaust emissions, and the speed will recover smoothly again.
4. Achieve low noise and soft sound quality
The new electronically controlled common rail engine achieves low noise with its unique fuel injection mode. Moreover, the improvement of the hydraulic pump also effectively controls the harsh sound generated when the hydraulic oil circuit is holding pressure.
5. EMC (electromagnetic suitability) has reached the European standard
In order to avoid electromagnetic wave in Weihai, corresponding countermeasures are taken.
New hydraulic system
For the pressure loss condition of the hydraulic pipeline, from the spool of the control valve to the joint, conduct a thorough inspection one by one. Adopt the latest high efficiency hydraulic pump to build a new hydraulic system which can minimize energy loss.
1. A new generation of electronically controlled engine
EGR equipment is equipped in the common rail ultra-high pressure injection engine to reduce the intake temperature and inhibit the oxygen concentration. Through the coordinated control of multi-stage injection, the pursuit of maximum fuel combustion efficiency, play a strong low torque. The fuel cost is saved and the emission of PM (particulate matter) and NOx (nitrogen oxides) is greatly reduced.
2. Integrated control through advanced ITCs system
The latest ITCs system, which controls the new generation of engine, can restrain the power loss of engine to the maximum extent when the hydraulic load changes sharply, and make the mechanical response more sensitive.
Stable car body and strengthened working device
In the car body and working device using durable structural parts, to ensure a reliable high-strength structure, so that the machine is more suitable for the demand of load operation.
1. Hd (high strength) forearm
At the bottom of the small arm, four stiffeners are added, and the length of the stiffeners is extended.
2. Bucket
The new type of bucket improves the digging performance, and improves the wear resistance and durability.
It is an abnormal operation switch to ensure the continuous operation of the machine.
Even if the mechanical and electrical control system of ITCs has unpredictable failure, they can make the machine continue to run by enabling the operation switch in the abnormal state. The standby system can automatically switch to the abnormal operation mode.
Parameter configuration of Kobelco SK380 excavator
Specifications
|
power |
traditional power |
| Tonnage (ton) | 38 |
| Operating weight (kg) | 38000 |
| Bucket capacity (M3) | 1.9 |
| Boom length (mm) | 5830 |
| Stick length (mm) | 2600 |
Dynamic System
| Engine model | Hino j08e |
| Rated power (kW / RPM) | 209/2100 |
| Displacement (L) | 7.684 |
| Form of work | Direct injection, turbocharged, built-in intercooler |
Body size
| Total transport length (mm) | 11280 |
| Total transport width (mm) | 3270 |
| Total transport height (mm) | 3640 |
| Full height of cab (mm) | 3233 |
