ISO9001 Polyester Powder Coated Steel Security Fence Panels Long Lifespan
Beautiful appearance long lifespan metal palisade fencing panels
Product Introduction
Steel Palisade Fencing, also known as European Style Fencing. In some countries people may not familiar with this type of fencing system, but many countries have already been using it to replace the traditional brick walls and heavy wire mesh fence, making the living environment beautiful, comfortable and fresh. "Palisade" is also called "Security Defense assembled pales", it comes into people's life because the pursuit of a better environment.
The most common specifications for Steel Palisade Fencing is 1.8M high and 2.5M wide. Preservative treatment of this type of fencing includes: electrostatic galvanized, hot dip galvanized, polyester powder coated, PVC coated, etc. Powder coated and PVC coated Steel Palisade Fencing due to its low price and durability are very popular among customers. Durable, strong corrosion-resistant, long service life are some of the characteristics of this type of fencing system.
Specifications of metal palisade fencing panels
a.Pales
| Width | 65-70mm |
| Thickness | 2.0-3.0mm |
| Finishing | galvanized and polyester powder coated or hot dipped galvanized |
| Head | single point, triple point |
| Height | 1.2m-3.0m |
b.Rail
| Size: | 50x50mm, 40x40mm (Angle Iron) |
| Thickness: | 5.0-6.0mm |
| Finishing: | galvanized and polyester powder coated or hot dipped galvanized |
| Holes: | with 19 holes drilled on one edge side |
| length | 2.7m |
| Screw Size: | M8 |
c.post
| H Post Size: | 100x68mm, 100x55mm, 120x74mm |
| Square Post Size: | 60*60mm, 80*80mm |
| Thickness: | 3.5mm-5.00mm |
| Finishing: | galvanized and polyester powder coated or hot dipped galvanized |
| Head: | cut sharp |
| Height: | on the basis of pale height (1.2-3.0m) |
Features of metal palisade fencing panels
Provides a physical and visible deterrent against intruders and accommodates difficult site conditions
Custom designs of palisade fencing can be manufactured to suit any site conditions eg base plates for bolting down to concrete or cranked posts for fixing to walls
No expensive equipment required should a damaged pale need to be replaced
Product has long life expectancy in service
Application for metal palisade fencing panels
- Business factories, warehouses, and offices.
- Gas & Water Utilities.
- Waste Depots.
- Council swimming pools and equipment yards.
- Schools.
- Police Fire and Ambulance stations.
- Any perimeter that requires a secure boundary and/or fence.
Our Service:
1. Before the order can be confirmed finally, we would strictly check the material, color, dimension of the sample step by step.
2. Our salesman, also as an order follower, would trace every phase of production from the beginning.
3. After the worker finished the production, our QC will check the overall quality.If not pass our standard will rework.
4.When packing the products, our Packing Department will check the products again.
5.Any small problem happening in our product will be solved at the most prompt time.
