Australia Standard 6 Rails Oval Pipe 1.8m×2.1m Steel Cattle Yard Panels
Easily Assembled Long Life Galvanized Cattle Panel Gate livestock panels
Brief Introduction
1. It is made with welded hot dip galvanized pipes for the use of fencing livestock, such as cattle,cow,bull,calves,Dairy sheep,goat,dog,etc.
2. We stock a large variety of cattle panels, many different lengths and sizes. Our panels come with pins, caps and feet.
3. Our cattle fence panel, made of high quality galvanized square, round and oval pipe is ideal for protecting horse. It has 3-7 rails to support the fence and each rails has different spacing to prevent horse hooves and feet from catching in the fence. It can be used at ranch, farm in shape of round pen and fence box based on the horses' height and number. Our fence panel is produced under professional cut short machine, welded team and packing technology.
Specification of Australia standard 1.8m×2.1m cattle yard panels
Each panel includes BosAg Branded Components:
2 x Foot Plates
2 x 180mm Drop Pins (tapered end)
2 x 40mm x 40mm Square Post Caps
2 x 40mm x 5mm FMS L Cleats used with slotted 20mm x 30mm holes
2 x 40mm x 5mm FMS C Cleats used with slotted 20mm x 30mm holes
| Horse Fence Panel | |
| Material | hot dipped galvanized square pipe, oval pipe and round pipe and RHS. |
| Dimension | height:1.8m;length:2.1m,3m |
| Vertical pipe | RHS:50 X 50 X 1.6 mm or round pipe:50 x 1.6 mm |
| Horizontal pipe |
a.round pipe: 32 x 1.6 mm,42 x 1.6 mm b.square pipe: 40 X 40 X 1.6 mm,50 x 50 x 1.6 mm c.oval pipe: 30 x 60 x 1.6 mm,40 x 80 x 1.6 mm |
| Bars/Rails | 6 bars/rails |
| Accessories | with hugs,caps and pins |
| Production Process | put the pipe on the welded shaping machine , the pipe are galvanized welded,the pipe according to the drawing,the last make the spot smoothing |
|
Advantage |
fence panel is light,easy to transport and install,ventilate diaphanous; high strength and tensil strength good pressure resistance,corrosion resistance and weather resistance;anti-oxidzing property |
Fuatures of Australia standard 1.8m×2.1m cattle yard panels
1
SAFETY
The consequences of an injury are unthinkable. Cattle can be unpredictable so having a strong safe yard gives you peace of mind.
2
RELOCATABLE
A Utility Yard System can be easily shifted if you sell your property or your needs change making it a smart investment.
3
EASY TO SET UP
The Utility Yards are easy to set up and come with an installation guide.
4
SCALABLE
If you livestock needs grow, then you can simply add and enlarge your Utility Yard to suit.
Technological process
1.Raw material 2. cutting 3.welding 4.cleaning 5.anti-rust painting 6.zinc spraying7.packing
Our service
(1) Factory directly sale.
(2) It can customized according to the requirements or drawings.
(3)With the fastest speed of delivery.
(4)Answer questions in a timely
(5)Enquiry will be replied in 2 hours.
(6)If you have any question,please tell me freely.
