2500mm Co Extrusion Cast Film Machines for Lldpe Bopp Air Bubble Hdpe
Price:
120000--220000 USD Per Set
MOQ:
1 set
Delivery Time:
2-3 months
Brand:
DaLi
Product Description
LLDPE /LDPE/HDPE Three Layers Stretching Film MachineFor 2500mm
three layers stretch film/cling film production line
- Overal view of the production line
. Cast Stretch Film Machine Triple Screw Plastic Extruder is the automatic All-in-one model which is designed according to the advanced technology from domestic and foreign markets, with auto cutting, auto laps changing apparatus and auto PLC system..
- Detaied of specifcations:Three-layer co-extrusion stretch film for DL-65/90/65---1500 Model
|
Material |
LDPE/LLDPE |
|
Working width |
2200mm max |
|
Thickness range |
0.012mm to 0.05mm |
|
Screw Dia. and L/D |
Φ90×33:1 X2;Φ110×33:1 X1 |
| T die width | 2500mm |
| Substrcture of Layer | Three layers ABC |
| Actual comsumption of power(KW) | 70 KW per hour |
| Power supply | Three Phase 380V( ±10% )50hz, Single Phase 220V50Hz |
| Mechanical speed: | 200m/min |
| Extrusion capacity | 250~300kg/h(varies with material) |
|
Installation power(KW) |
About 160kw ( actual consumption is 40%-50% of total installation power) |
| Installation space |
L=7.5M; W=3m; H=3.5m
|
Scene of assmebly workshop
