Heat Exchanger 25.4mm OD Steel Tube A210 A1 25.4*2.11 ASTM Carbon Steel Pipe
ASTM A210 A1 25.4*2.11 Carbon heat exchanger cold drawing steel tube
Our ASME SA 210 Gr. A1 Boiler Tubing is highly commended by the clients for its on-time execution. Our clients can avail of this ASTM A210 Grade A1Steam Boiler Piping in different grades and dimensions as per the requirement and choice of the clients. This ASTM A210 Gr. A1 Boiler Pipes Insulation is sternly inspected by the best quality inspectors in order to deliver defect-free range to the clients.
ASTM A210 Grade A-1 Carbon Steel Seamless Tubes are Medium Carbon Steel Tubes with max 0.27 % carbon content with a combination of max 0.93 % manganese.
These Tubes are most commonly used for general purpose applications worldwide. ASTM A210 Grade A-1 Tubes are ductile and strong Tubes with long-wearing properties.
These Tubes are manufactured as per ASTM Specification and commercially referred as carbon steel Tubes.
Specifications:
Grade and Chemical Composition ( ％ )
|
Grade |
C |
Mn |
P |
S |
Si |
|
A-1 |
≤ 0.27 |
≤ 0.93 |
≤ 0.035 |
≤ 0.035 |
≥ 0.10 |
|
C |
≤ 0.35 |
0.29-1.06 |
≤ 0.035 |
≤ 0.035 |
≥ 0.10 |
Mechanical properties
|
Grade |
Tensile Point |
Yield Point |
Elongation |
|
A-1 |
≥ 255(37) |
≥ 415(60) |
≥ 30% |
|
C |
≥ 275(40) |
≥ 485(70) |
≥ 30% |
