Hot Dipped Galvanized Or PVC Coated High Security Chain Link Fence Metal Border Fence
Border Fence Description
Border chain link fences have other names like diamond mesh fences, cyclone fences. The chain link wire mesh is formed by twisting wire raw material together. There are also two kinds of edges which are folded edge and twisted edge. The raw materials can be galvanized steel wire or PVC coated steel wire. The latter one can have custom colors and the most popular one is dark green.
Border chain link fences are widely used in road, railway and highway fencing projects. And this fencing product is also used for interior decoration, fowl and small animal raising like chickens, ducks, geese, rabbits and also zoo fencing projects. Other scenarios using Chain Link Fences are machinery and equipment protection, sports venues, green belt. Sometimes people use Chain Link Fences as gabions by forming a box shape with it and filling it with stones. It can also be used for the protection and support of seawalls, hills, bridges and reservoirs, and other civil works. It is a great material for flood control.
Besides, border chain link fences can also be used for handicraft material, warehouses protection, cold storage protection and building site protection, and so on. As you can see, Chain Link Fences really does a great job for so many fencing scenarios. It's cost-effective and quite good-looking. It's an pretty ideal fencing choice for everybody.
Border Fence Pole Specification
| Panel Height | Panel Length | Wire Dia | Mesh Size | Folds No. |
| H=1.03m | L=2.5m | 4.0mm | 50*200mm | 2 |
| H=1.23m | L=2.5m | 4.0mm | 50*200mm | 2 |
| H=1.53m | L=2.5m | 4.0mm | 50*200mm | 3 |
| H=1.73m | L=2.5m | 4.0mm | 50*200mm | 3 |
| H=2.03m | L=2.5m | 4.0mm | 50*200mm | 4 |
| Color |
RAL6005 Green, RAL7016 Gray, RAL9005 Black, RAL9010 White, ETC |
|||
| Type | X*Y*TW | 1.0m | 2.0m | 2.3m | 2.5m | 2.7m | 2.8m | 3.0m | 3.2m | 4.0m | 6.0m |
|
SHS |
50*50*1.2 | 1.872 | 3.744 | 4.3056 | 4.68 | 5.0544 | 5.2416 | 5.616 | 5.9904 | 7.488 | 11.232 |
| 50*50*1.5 | 2.34 | 4.68 | 5.382 | 5.85 | 6.318 | 6.552 | 7.02 | 7.488 | 9.36 | 14.04 | |
| 60*60*1.5 | 2.8 | 5.6 | 6.44 | 7 | 7.56 | 7.84 | 8.4 | 8.96 | 11.2 | 16.8 | |
| 60*60*2.0 | 3.73 | 7.46 | 8.579 | 9.325 | 10.071 | 10.444 | 11.19 | 11.936 | 14.92 | 22.38 | |
| 76*76*1.5 | 3.51 | 7.02 | 8.073 | 8.775 | 9.477 | 9.828 | 10.53 | 11.232 | 14.04 | 21.06 | |
| 76*76*2.0 | 4.68 | 9.36 | 10.764 | 11.7 | 12.636 | 13.104 | 14.04 | 14.976 | 18.72 | 28.08 | |
| 100*100*3.0 | 9.36 | 18.72 | 21.528 | 23.4 | 25.272 | 26.208 | 28.08 | 29.952 | 37.44 | 56.16 | |
| 100*100*4.0 | 12.4 | 24.8 | 28.52 | 31 | 33.48 | 34.72 | 37.2 | 39.68 | 49.6 | 74.4 | |
|
CHS |
42*1.2 | 1.2 | 2.4 | 2.76 | 3 | 3.24 | 3.36 | 3.6 | 3.84 | 4.8 | 7.2 |
| 42*1.5 | 1.49 | 2.98 | 3.427 | 3.725 | 4.023 | 4.172 | 4.47 | 4.768 | 5.96 | 8.94 | |
| 48*1.2 | 1.38 | 2.76 | 3.174 | 3.45 | 3.726 | 3.864 | 4.14 | 4.416 | 5.52 | 8.28 | |
| 48*1.5 | 1.71 | 3.42 | 3.933 | 4.275 | 4.617 | 4.788 | 5.13 | 5.472 | 6.84 | 10.26 | |
| 60*1.5 | 2.15 | 4.3 | 4.945 | 5.375 | 5.805 | 6.02 | 6.45 | 6.88 | 8.6 | 12.9 | |
| 60*2.0 | 2.85 | 5.7 | 6.555 | 7.125 | 7.695 | 7.98 | 8.55 | 9.12 | 11.4 | 17.1 | |
| 76*2.0 | 3.64 | 7.28 | 8.372 | 9.1 | 9.828 | 10.192 | 10.92 | 11.648 | 14.56 | 21.84 | |
| 76*2.5 | 4.52 | 9.04 | 10.396 | 11.3 | 12.204 | 12.656 | 13.56 | 14.464 | 18.08 | 27.12 | |
| 89*3.0 | 6.34 | 12.68 | 14.582 | 15.85 | 17.118 | 17.752 | 19.02 | 20.288 | 25.36 | 38.04 | |
| 89*4.0 | 8.36 | 16.72 | 19.228 | 20.9 | 22.572 | 23.408 | 25.08 | 26.752 | 33.44 | 50.16 | |
|
RHS |
40*60*1.2 | 1.87 | 3.74 | 4.301 | 4.675 | 5.049 | 5.236 | 5.61 | 5.984 | 7.48 | 11.22 |
| 40*60*1.5 | 2.34 | 4.68 | 5.382 | 5.85 | 6.318 | 6.552 | 7.02 | 7.488 | 9.36 | 14.04 | |
| 40*80*2.0 | 3.74 | 7.48 | 8.602 | 9.35 | 10.098 | 10.472 | 11.22 | 11.968 | 14.96 | 22.44 | |
| 60*80*2.0 | 4.36 | 8.72 | 10.028 | 10.9 | 11.772 | 12.208 | 13.08 | 13.952 | 17.44 | 26.16 | |
| 60*80*2.5 | 5.46 | 10.92 | 12.558 | 13.65 | 14.742 | 15.288 | 16.38 | 17.472 | 21.84 | 32.76 | |
| 100*50*2.0 | 4.68 | 9.36 | 10.764 | 11.7 | 12.636 | 13.104 | 14.04 | 14.976 | 18.72 | 28.08 | |
| 80*120*2.0 | 6.24 | 12.48 | 14.352 | 15.6 | 16.848 | 17.472 | 18.72 | 19.968 | 24.96 | 37.44 | |
| 80*120*2.5 | 7.8 | 15.6 | 17.94 | 19.5 | 21.06 | 21.84 | 23.4 | 24.96 | 31.2 | 46.8 | |
| IPE | 55*100*3.6 | 6.72 | 13.44 | 15.456 | 16.8 | 18.144 | 18.816 | 20.16 | 21.504 | 26.88 | 40.32 |
| 68*100*4.5 | 9.46 | 18.92 | 21.758 | 23.65 | 25.542 | 26.488 | 28.38 | 30.272 | 37.84 | 56.76 | |
| 64*120*3.8 | 8.36 | 16.72 | 19.228 | 20.9 | 22.572 | 23.408 | 25.08 | 26.752 | 33.44 | 50.16 | |
| 64*120*4.8 | 11.5 | 23 | 26.45 | 28.75 | 31.05 | 32.2 | 34.5 | 36.8 | 46 | 69 | |
| ISA | 40*40*4 | 2.42 | 4.84 | 5.566 | 6.05 | 6.534 | 6.776 | 7.26 | 7.744 | 9.68 | 14.52 |
| 50*50*5 | 3.77 | 7.54 | 8.671 | 9.425 | 10.179 | 10.556 | 11.31 | 12.064 | 15.08 | 22.62 | |
| 60*60*6 | 5.42 | 10.84 | 12.466 | 13.55 | 14.634 | 15.176 | 16.26 | 17.344 | 21.68 | 32.52 | |
| 75*75*6 | 6.91 | 13.82 | 15.893 | 17.275 | 18.657 | 19.348 | 20.73 | 22.112 | 27.64 | 41.46 | |
| I POST | 44*70*1.5 | 2.95 | 5.9 | 6.785 | 7.375 | 7.965 | 8.26 | 8.85 | 9.44 | 11.8 | 17.7 |
| 44*70*2.0 | 3.93 | 7.86 | 9.039 | 9.825 | 10.611 | 11.004 | 11.79 | 12.576 | 15.72 | 23.58 | |
| 55*100*1.5 | 3.73 | 7.46 | 8.579 | 9.325 | 10.071 | 10.444 | 11.19 | 11.936 | 14.92 | 22.38 | |
| 55*100*2.0 | 4.97 | 9.94 | 11.431 | 12.425 | 13.419 | 13.916 | 14.91 | 15.904 | 19.88 | 29.82 | |
| PEACH POST | 50*70*1.2 | 1.68 | 3.36 | 3.864 | 4.2 | 4.536 | 4.704 | 5.04 | 5.376 | 6.72 | 10.08 |
| 70*100*1.2 | 3.55 | 7.1 | 8.165 | 8.875 | 9.585 | 9.94 | 10.65 | 11.36 | 14.2 | 21.3 | |
| C POST | 60*80*2.0 | 4 | 8 | 9.2 | 10 | 10.8 | 11.2 | 12 | 12.8 | 16 | 24 |
| 60*80*2.5 | 5 | 10 | 11.5 | 12.5 | 13.5 | 14 | 15 | 16 | 20 | 30 | |
| EURO POST | 48*1.5 | 1.85 | 3.7 | 4.255 | 4.625 | 4.995 | 5.18 | 5.55 | 5.92 | 7.4 | 11.1 |
| 60*1.5 | 2.29 | 4.58 | 5.267 | 5.725 | 6.183 | 6.412 | 6.87 | 7.328 | 9.16 | 13.74 |
Border Fence Process
Booking the material wire and pipe material
material wire zinc coating test
welding wire mesh and cut pipe as size
Paint or galvanized for the panel and pipe
package and loading
Quality Control Process
Galfan wire or hot dipped galvanized test the Zn/Ai coating
Semi-finished product test the hole size and panel size
Finished Product’s installation
ZERUN Service
We can provide most of free samples .
We have been in providing the professional products in wire mesh fence field for 15 years.
We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure.
If there are some defective items, we usually credit to our customer or replace in next shipment.
Payment Term
T/T,30% in advance and the balance 70% against the copy of B/L.
Other payment term we can discuss.
