10 Gauge Galvanised Steel Mesh Rolls , PVC Coated Iron Welded Wire Fence Roll 1/2 Hole
10 Gauge Stainless Steel Or PVC Coated 1/2 Mesh Hole Welded Iron Wire Mesh Roll
Product Introduction
Welded wire mesh panel is made of superior quality carbon steel wire,electro galvanized, hot dipped galvanized or plastic coated. It is also supplied in plain steel or rebar without galvanizing to save cost.
Popular size of welded wire mesh panel for fly pen and dog kennel.
Wire gauge:10 gauge, 11 gauge, 12 gauge(other diameter is also available)
Mesh opening: 5x5cm, 75x75cm, 5x10cm, 8x12cm ( other mesh is also available )
Welded wire mesh is extensively used in industry and agriculture, building, transportation and mining for all such purposes as poultry houses, egg baskets, runway enclosures, draining rack, fruit drying screen fence.
For finish, we can supply the following kinds:
* Hot-dipped galvanized after welding
* Hot-dipped galvanized before welding
* Electro galvanized after welding
* Electro galvanized before welding
* PVC coated
* In stainless steel
Packing:
* Each roll packed by water proof paper.
* Each roll shrink wrapped.
Other packing method may be accepted after confirmation.
The good quality of our products can be touched by our customer from below details when compared
with other suppliers.
* Material(Wire)
* Mesh
* Performance
* Life span
Materials
Materials applied for welded wire mesh products include Low carbon steel wire, stainless steel wire, iron wire, galvanized steel wire, PVC coated iron wire in blue, green, yellow and other colors.
1. Strong welded and bright luster. 2 inch by 4 inch openings keep out pests and small critters
2. Strong mesh, won’t come loose if cut in pieces or under pressure.
3. Galvanized before welding. Anti-corrosive and anti-rust.
4. Great for property boundaries, enclosing gardens and more
Supplying forms: In rolls or panels with customized size
Specification
|
Specification in British System |
Specification in British System |
|
|
Width/length:3'x100' |
Width/length:0.914mx30.48m |
|
|
Width/length:4'x100' |
Width/length:1.219mx30.48m |
|
|
Mesh |
Wire Dia. in BWG |
Mesh |
|
1"x2" |
14 15 16 17 |
25.4mmx50.8mm |
|
1"x1" |
14 15 16 17 18 19 |
25.4mmx50.8mm |
|
3/4"x3/4" |
16 17 18 19 20 |
19.05mmx19.05mm |
|
1/2"x1" |
17 18 19 20 21 22 |
12.7mmx25.4mm |
|
1/4"x1/4" |
23 |
6.35mmx6.35mm |
|
3/8"x3/8" |
21 |
9.35mmx9.35mm |
Welded Wire Mesh Applications
Welded wire mesh‘s combination of low cost, ease of use and versatility makes it a popular choice for many different applications.
1.Fences and gates: You’ll find welded wire mesh fences and gates installed at residences and all types of commercial and industrial properties.
2.Architectural uses such as building facades: Although welded wire fabric is known for its strength and durability, architects and designers often use it to enhance aesthetic appeal.
3.Architectural Wire Mesh for Green Building Design: Using welded wire mesh can help achieve LEED (Leadership in Energy and Environmental Design) credits and certification.
4.Infill panels for railings and divider walls: Woven wire infill panels are used often as partitions or divider walls due to its clean and sometimes modern look.
5.Animal control: Farmers, ranchers and animal control professionals use fencing made from welded wire mesh to contain livestock and stray animals.
6.Screens for doors and windows: Welded wire mesh screens provide a sturdy material and effective insect control when installed in windows.
We offer various types of welded wire mesh for your options. It is customized product based on each client's needs.
