Galfan Army Using 4.5mm Military Barrier Welded Gabion

Price Negotiable

Price: USD9.5-39.5/m

MOQ: 50 sets

Delivery Time: 14-21 per working days

Brand: ZERUN

Product Description

Hesco Mil 3 Hot-Dipped Galvanized Military Barrier

1.Military barrier introduce:

Militar Barrier , which is made of the steel welded mesh and lined with non-woven geotextile , can be filled with sand, earth, cement, stone, then as a defence wall or bunker and widely used in the military to protect safety.

2.Military barrier information:

name	Military barrier	main Material	Geotextile and welded gabion
Hole Shape	Square Hole	Geotextile Color	Green or beige
main Material	Geotextile and welded gabion	Geotextile Weight	250-500g/m2
wire Surface	Galvanized or galfan	Packing	Pallet
Wire Diameter	4.0 4.5 5.0mm	Feature	Easily Assembled
Application	Military Sand Wall, Flood barrier	Usage	Protection

3.Military barrier specification:

Unit Type	Height	Width	Length	Internal Cells
ZERUN-1	1.37m/4’6’’	1.06m/3’6’’	10m/32’	9 cells(4+5)
ZERUN-2	0.61m/2’	0.61m/2’	1.22m/4’	10 cells(5*2)
ZERUN-3	1.0m/3’3’’	1.0m/3’3’’	10m/32’	10 cells(5*2)
ZERUN-4	1.0m/3’3’’	1.5m/5’	10m/32’	10 cells(5*2)
ZERUN-5	0.61m/2’	0.61m/2’	3.05m/10’	5 cells(5*1)
ZERUN-6	1.68m/5’6’’	0.61m/2’	3.05m/10’	5 cells(5*1)
ZERUN-7	2.21m/7’3’’	2.13m/7’	27.74m/90’	13 cells(5+4+4)
ZERUN-8	1.37m/4’6’’	1.22m/4’	10m/32’	9 cells(5+4)
ZERUN-9	1.0m/3’3’’	0.76m/2’6’’	9.14m/30’	12 cells(6*2)
ZERUN-10	2.12m/7’	1.52m/5’	30.5m/95’	20 cells(5*4)
ZERUN-11	2.74m/9’	1.06m/3’6’’	3.3m/11’3’	3 cells(3*1)
ZERUN-12	2.1m/7’	1.06m/3’6’’	33m/108’	30 cells(5*6)
