Oil Basin 5.0mm Military Barrier Beige Geotextile Retaining Wall

Price Negotiable

Price: USD9.5-39.5/m

MOQ: 50 sets

Delivery Time: 14-21 per working days

Brand: ZERUN

Product Description

Hesco Mil 8 Hot-Dipped Galvanized Military Sand Barrier

1.Military barrier introduce:

Military Barrier is a prefabricated, multi-cellular system, made of Zinc-Aluminum coated welded gabion and lined with geotextile. Units can be extended and joined using the provided joining pins.It is easy installed with using minimal man power and commonly available equipment.After extended,it is suitable for filling with earth,sand,stone,or other general materials.then hesco barrier like a defence wall or bunker,it is widely use in military to protect safety.

2.Military barrier information:

name	Military barrier
Hole Shape	Square Hole
Hole Size	76.276.2mm/3''3'' etc
main Material	Geotextile and welded gabion
Geotextile Color	Green or beige
Geotextile Weight	250-500g/m2
wire Surface	Galvanized or galfan
Wire Diameter	4.0 4.5 5.0mm
Application	Military Sand Wall, Flood barrier
Feature	Easily Assembled
Usage	Protection
Highth	1.37m 0.61m 1.0m 1.6m etc
Connection	Spiral

3.Military barrier specification:

Unit Type	Height	Width	Length	Internal Cells
ZERUN-1	1.37m/4’6’’	1.06m/3’6’’	10m/32’	9 cells(4+5)
ZERUN-2	0.61m/2’	0.61m/2’	1.22m/4’	10 cells(5*2)
ZERUN-3	1.0m/3’3’’	1.0m/3’3’’	10m/32’	10 cells(5*2)
ZERUN-4	1.0m/3’3’’	1.5m/5’	10m/32’	10 cells(5*2)
ZERUN-5	0.61m/2’	0.61m/2’	3.05m/10’	5 cells(5*1)
ZERUN-6	1.68m/5’6’’	0.61m/2’	3.05m/10’	5 cells(5*1)
ZERUN-7	2.21m/7’3’’	2.13m/7’	27.74m/90’	13 cells(5+4+4)
ZERUN-8	1.37m/4’6’’	1.22m/4’	10m/32’	9 cells(5+4)
ZERUN-9	1.0m/3’3’’	0.76m/2’6’’	9.14m/30’	12 cells(6*2)
ZERUN-10	2.12m/7’	1.52m/5’	30.5m/95’	20 cells(5*4)
ZERUN-11	2.74m/9’	1.06m/3’6’’	3.3m/11’3’	3 cells(3*1)
ZERUN-12	2.1m/7’	1.06m/3’6’’	33m/108’	30 cells(5*6)
