1100 1060 Aluminum Sheet 0.5mm Thickness for Food Packaging/Electronic Heat Dissipation
Price:
3000-3600 USD/Ton
MOQ:
2 Tons
Delivery Time:
7-20 workdays
Brand:
Yongsheng
Product Description
1100 1060 Aluminum Sheet 0.5mm Thickness
Premium aluminum sheet specifically designed for food packaging and electronic heat dissipation applications, featuring 0.5mm thickness for optimal performance.
Aluminum Alloy Series Overview
| Alloy Series | Core Features | Typical Applications |
|---|---|---|
| 1000 Series | Pure Aluminum Plate - Soft texture, extremely corrosion-resistant, excellent electrical/thermal conductivity, low strength, easy to process |
|
| 2000 Series | Al-Cu Alloy Plate - High strength, resistant to high temperatures, requires surface treatment for corrosion protection |
|
| 3000 Series | Al-Mn Alloy Plate - Medium strength, excellent corrosion resistance, good plasticity, easy to weld |
|
| 4000 Series | Al-Si Alloy Plate - Low melting point, wear-resistant, primarily used in casting materials |
|
| 5000 Series | Al-Mg Alloy Plate - High strength, extremely strong corrosion resistance, excellent low-temperature performance, easy to shape |
|
| 6000 Series | Al-Mg-Si Alloy Plate - Heat-treatable strengthening, medium strength, excellent corrosion resistance, superior machinability |
|
| 7000 Series | Extremely high strength, requires corrosion protection, premium pricing |
|
Technical and Process Advantages
Mature Smelting and Casting Technologies: Our factory maintains precise temperature control for various aluminum plate materials including 1 series (pure aluminum), 3 series (aluminum-manganese alloy), and 5 series (aluminum-magnesium alloy). Pure aluminum melting temperature is precisely controlled within 660-700℃. Advanced degassing and slag removal processes minimize internal defects, with mechanical properties fluctuating within ±5% range - significantly better than the industry average of ±8%.
High-Precision Rolling and Surface Treatment: Equipped with upgraded four-roll reversible cold rolling machines capable of processing aluminum plates from 0.1mm to 10mm thickness. Thickness tolerance reaches as low as ±0.01mm, meeting stringent requirements for electronics and packaging applications. Full range of surface treatments including anodizing, electro-etching coating, and film coating available with custom finishes (mirror, matte, or brushed). Coatings pass salt spray testing (neutral salt spray test ≥ 500 hours).
Rapid Custom Process Response: Our established "process parameter database" enables quick matching of exclusive production processes for specialized applications including marine-grade 5 series aluminum plates and automotive 3 series lightweight aluminum plates. Custom order process confirmation cycle is 30% shorter than industry average.
Quality Control Management
Rigorous Raw Material Selection: We exclusively use high-purity aluminum ingots meeting GB/T3190 (China) or ASTMB209 (USA) standards with aluminum content ≥ 99.7%. Each batch undergoes spectrometer composition testing to prevent performance issues from impurities.
Real-Time Production Monitoring: Key processes (melting, rolling, annealing) feature online detection equipment with real-time composition and temperature monitoring. Laser thickness gauges control rolling precision while thermocouples monitor furnace temperature uniformity. Production data is recorded every 10 minutes for complete traceability.
Comprehensive Finished Product Inspection: Four-level inspection protocol covering appearance, dimensions, performance, and weather resistance. Visual and light detection for appearance, micrometers and vernier calipers for dimensional checks (≥5% sampling rate), universal material testing for mechanical properties, and high/low temperature cycling tests (-40℃ to 80℃, 50 cycles) for outdoor applications. Non-conforming products receive 100% rework with factory pass rate consistently exceeding 99.8%.
Product Details
Product Applications
