17 Pin Sensor Cable M12 Waterproof Connector Male To Male PA66

Price Negotiable

Price: negotiable

MOQ: 10

Delivery Time: 7~14

Brand: RIGOAL

Product Description

M12 Waterproof Male To Male A/B/D Coding 3pin 4pin 5pin 8pin 12pin 17pin Sensor Cable Connector

The M12 series features sensor and actuator connectors with locking thread for electronics automation, process control,

and commercial electronics.

We offer many different cable connectors, panel mount receptacles, field attachable/ installable connectors and various

accessories.

Our connectors have industry standard A/B/C/D/S/T/X cording, for both screw locking and quick-locking styles.

High degree of protection IP67, safe to use on site 2. High quality gold-plated solid phosphor bronze contacts , ≥ 600 times

mating life 3. Anti-vibration locking screw design 4. Support samples, retail and bulk order


			item

			value

			Place of Origin

			China

			Guangdong

			Brand Name

			Rigoal connector(RG)

			Model Number

			M12 molding connector cable

			Type

			M12

			Application

			Automotive

			Gender

			Male

			Product name

			M12 8pin molding cable

			Application

			Sensor or Automation

			Coupling nut/screw

			Brass with nickel plated

			Standard

			IEC61076-2-101

			Contacts

			3 4 5 6 8 12pins

			Contact way

			solder

			IP degree

			IP67/IP68

			Type

			M12

			Material

			PA66

			Certificate

			CE IP68 ROHS
