AWG18 M12 Male Assembly Waterproof Connector IEC IP67 Female
M12 male assembly waterproof connector
Specifications:
| Housing Material / Color | Nylon / Black |
| Contacts | Brass / Gold |
| Coupling Nut Material / Plating | Brass / Nickel |
| O-ring Material | NBR |
| Operating Current | 4A |
| Operating Voltage | 250V |
| Operating Temperature | -25℃ ~ +85℃ |
| Protection Class | IEC IP67 |
| Cable Diameter | 4-8MM |
| Connection Method | Screw Connection |
| Conductor Cross Section(AWG) | 26-18AWG(0.14-0.75mm²) |
About M12 connectors:
The M12 series features sensor and actuator connectors with locking thread for electronics automation, process control, and commercial electronics.
We offer many different cable connectors, panel mount receptacles, field attachable/ installable connectors and various accessories.
Our connectors have industry standard A/B/C/D/S/T/X cording, for both screw locking and quick-locking styles.
Product diagram
 |
Product Name: M12 female connector angled plastic assembly waterproof connector Model number:M12P-D-S Series:M12 Connector |
Certifications
Package&Shipping:
1. Generay Package :Each pcs put in one samll waterproof PE bag,then put in a carton Details: Add the label, about 200 hundred pieces connector put in one carton, Carton size:40*30*30cm
2. OEM/ODM package is available
3. According to customer choice.
Our Services
1. Low MOQ: It can meet your business very well.
2. Good services: We treat you as our friends.
3. Packaging: Package will do after several discussions with you.
4. Best price: The products are directly from our factory. So it saves a lot secondary cost.
5. Good quality: The only will start after you confirm the samples and the products will do 100% inspection before shipping.
6. OEM accepted: Please send us your design and other important information. OEM are always welcome.
