200Nm3 Small-Scale Hydrogen Production Unit From Lndustrial Methanol
Technology Application
Techairs is professional engaged in gas preparation, separation and purification technology research and development and engineering transformation. It is widely used in petrochemical industry, coal chemical industry, fine chemical industry, gas industry, ethanol industry, photovoltaic semiconductor industry and PTA industry.Unique THiPSATM technology and FrTPSA technology can achieve high purity, high yield, low material consumption and low energy consumption; Separation of multicomponent gas and low separation coefficient gas.
Key figures
Feedstock: hydrogen rich gas, synthesis gas
Capacity: 100 to 100 000 normal cubic meters per hour (Nm3/h)
Adsorbtion pressure: 6 to 30 bar
H2 recovery rate: 80 to 95%
Turndown: 30 to 110%
General equipment and valves
| S/N | Item No. | Equipment Name | Unit | Qty. | Material |
| 1 | T0101A~H | Absorption towers A~F | Set | 6 | Q345R |
| 2 | V0101 | Buffer tank of feed gas | Set | 1 | Q345R |
| 3 | V0102 | Buffer tank of product gas | Set | 1 | Q345R |
| 4 | V0403 | Tank of negative direction discharge | Set | 1 | C.S |
| 5 | V0404 | Tank of positive direction discharge | Set | 1 | C.S |
| 6 | V0405 | Buffer tank of desorbed gas | Set | 1 | C.S |
| 7 | KV0101A-KV0107H | Program control valve | Set | 42 | S.S |
Features and advantages:
Mature process technology and safe and reliable operation.
Wide source of raw material and large processing scale.
Advanced recovery technology of thermal energy and low consumption of production energy.
Related qualifications and patents
Relying on its ability to research and develop, Techairs has obtained 90 International and domestic patents, more than 100 patent applications, 13 identified scientific and technological achievements, 4 awards for scientific and technological progress, 7 scientific and technological funding, 33 trademarks and 5 provincial and ministerial level scientific and technological progress awards. Obtained environment/quality management system certificate, HSE management system evaluation certificate.
• Class B qualification of engineering design and EPC contract
• Class III pressure vessel A1/A2 design qualification
• GC1,GC2 pressure pipe qualification
• Pressure vessel, pressure pipe and boiler installation qualification
• Class A certificate of provincial environmental pollution control level
• Fire design qualification
