P4.81 Outdoor Rental LED Display
P4.81 Rental Outdoor LED Display 500x500mm Cabinet 64x64 Dots Resolution
-With various real-time signal sources and the SMD encapsulation technology, its purpose is to playthe important news or events or TV program and more
-Super-thin and light cabinet can save room and time of installation
-High and adjustable brightness can meet the demands of the changing requirement of customer in different environments
-No mosaic due to excellent flatness and nice uniformity of light-emitting
-Wide viewing angle and the horizontal angle can reach 120° the images effect will not change largely in the range
-Single-lamp maintenance with low cost
-Good heat dissipation capability because of the unique design of vent fan
-Environment-friendly and energy-saving
1,High brightness /refresh rate
2,Vivid and colorful display
3,Impact resistant,adapt to kinds of weather
4,Quick response
5,Energy-saving, high luminance, environment-friendly
6,Low deficiency rate and low cost
7,Support various interfaces and signal sources, support multi-transmission methods, network control and automatic brightness control
P4.81 indoor LED displayAdvantage:
1, ISO9001, CE, RoHs
2, Stable and short delivery time
3, High quality with competitive price
4, 1 year warranty and good after-sale service
5, Strong quality control and R&D ability
6, Performance advantage
Module Parameter:
| Pixel pitch | 4.81mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD 1921 |
| Module size | 250x250mm |
| Module weight | 0.35kg |
| Module resolution | 52x52dots |
| Module quantity per cabinet | 4pcs |
Cabinet Parameter:
| Cabinet size | 500x500mm |
| Cabinet material | die- casting aluminum |
| Cabinet weight | 6.5kg |
| Cabinet resolution | 104x104 dots |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter
| Pixel density | 43264dots/m² |
| Brightness | ≥5000 cd/m² |
| Viewing angle | H≥120° V≥120° |
| Min.viewing distance | 4m |
| Max.power consumption | 900W/m² |
| Avg.power consumption | 330 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 14-16bits |
| Frame frequency | ≥1000frames/s |
| Refresh rate | ≥1920Hz |
| MTBF | ≥50000 hours |
| Lifespan | ≥100000 hours |
| Operating temperature | -10℃ ~ +60℃ |
| Storage temperature | -20℃ ~ +60℃ |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, internet etc. |
Buying Guides
In order to offer you a suitable solution, please follow the guides bellowing :
1,Dimension (Width and Height)
2,Location of installation. (picture is best)
3,Purpose. ( rental or use by youself)
4,Star effect or video effect which you need.
company profile
Shenzhen X-Media Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
Certificate
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
