DPF (Diesel Particulate Filter)
DPF (Diesel Particulate Filter) Technology of WFEC
| Item | Focus of WFEC DPF Technology |
| 1 | High filtration efficiency & low back pressure |
| 2 | Different materials, different structure, different coating processes |
| 3 | Soot loading model research |
| 4 | Washcoat distribution design & preliminary development of coating process |
| 5 | Washcoat materials design |
What is DPF (Diesel Particulate Filter)?
A diesel particulate filter (DPF) removes particulate matter from diesel exhaust by physical filtration. Many filter types are available but the most common type is a ceramic (cordierite or silicon carbide) honeycomb monolith.
The structure is like an emissions catalyst substrate but with the channels blocked at alternate ends. The exhaust gases must therefore flow through the walls between the channels and the particulate matter (PM) is deposited on the walls.
The filtration efficiencies of diesel particulate filters is >99% for solid matter. Since diesel particulate matter has a non-solid portion, the total efficiency for this is lower than this >90%.
All particulate filter systems include some means of regeneration.
DPF Substrate Parameters:
| Material | SiC-1 | SiC-2 | Cordierite-1 | Cordierite -2 |
| Porosity | 41% | 42% | ~52% | ~50% |
| Average pore diameter | 11um | 11um | ~13um | ~18 µm |
| CPSI/wall thickness | 300/12 | 350/11 | 300/9 | 300/9 |
DPF (Diesel Particulate Filter) Development:
To meet China Stage VI / Euro 6 and above emission regulations, WFEC has developed the catalysts and coating process technology for DPFs. The catalyst coated in the pores of the filter wall can improve passive regeneration to extend regeneration intervals and cut the fuel cost, as well as the reduction of HC and CO. The CDPFs with lower back pressure and better catalytic activity can be applied to various diesel vehicles.
| Specification | Diameter (mm) | Length (mm) |
Cell Density (CPSI) | Emission Standard |
| Ø143.8*152.4 | 143.8 | 152.4 | 200/300 | Euro 5, Euro 6 |
| Ø143.8*177.8 | 143.8 | 177.8 | 200/300 | Euro 5, Euro 6 |
| Ø143.8*200 | 143.8 | 200 | 200/300 | Euro 5, Euro 6 |
| Ø143.8*203.2 | 143.8 | 203.2 | 200/300 | Euro 5, Euro 6 |
| Ø152.4*304.8 | 152.4 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø160*100 | 160 | 100 | 200/300 | Euro 5, Euro 6 |
| Ø165*130 | 165 | 130 | 200/300 | Euro 5, Euro 6 |
| Ø170.2*203.2 | 170.2 | 203.2 | 200/300 | Euro 5, Euro 6 |
| Ø172*152.4 | 172 | 152.4 | 200/300 | Euro 5, Euro 6 |
| Ø190.5*203.2 | 190.5 | 203.2 | 200/300 | Euro 5, Euro 6 |
| Ø190.5*304.8 | 190.5 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø215.9*304.8 | 215.9 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø228*228 | 228 | 228 | 200/300 | Euro 5, Euro 6 |
| Ø228*304.8 | 228 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø230*152.4 | 230 | 152.4 | 200/300 | Euro 5, Euro 6 |
| Ø240*304.8 | 240 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø241.3*304.8 | 241.3 | 304.8 | 200/300 | Euro 5, Euro 6 |
| Ø266.7*152.4 | 266.7 | 152.4 | 200/300 | Euro 5, Euro 6 |
| Ø266.7*215 | 266.7 | 215 | 200/300 | Euro 5, Euro 6 |
| Remark: | Other sizes can be customized according to customer requirements. | |||
