Fast Pcb Assembly Service First Article Inspection DFM DFA Check
First Article Inspection DFM And DFA Check AOI PCB Assembly
Electronic Product design services include:
Systems Architecture
PCB Design (PCB Layout Design)
PCB Design Analysis (Signal Integrity Analysis, EMI analysis, Thermal Analysis, Reliability Analysis)
Embedded Software Development and Electronic Manufacturing (PCB Fabrication, PCB Assembly)
PCB capability:
| SMT Line | 8 lines |
| Capacity: | 9 million Placements per Day |
| Maximum PCB size: | 1200x 500mm |
| Minimum chip size: | 0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
| Maximum BGA size: | 74x74mm |
| BGA ball pitch: | 1.00mm (minimum), 3.00mm (maximum) |
| BGA ball diameter: | 0.40mm (minimum), 1.00mm (maximum) |
| QFP lead pitch: | 0.38mm (minimum), 2.54mm (maximum) |
| Assembly type: | Surface mount(SMT) assembly |
| DIP assembly | |
| Mixed(surface mount and through hole) technology | |
| Single or double sided placement | |
| Cable assembly | |
| Components type: | Passive components: |
| As small as 0201 package | |
| Ball Grid Arrays(BGA): | |
| As small as .5mm pitch | |
| Parts procurements: | Turnkey(we supply the parts) |
| Consigned(you supply the parts) | |
| You supply some parts, we do the rest | |
| Solder type: | Leaded/Lead-free |
| Testing: | X-Ray Inspection,AOI Testing,ICT,Flyingp Probe,In-circuit test |
Automated optical inspection (AOI) is an automated visual inspection of printed circuit board (PCB) (or LCD, transistor) manufacture where a camera autonomously scans the device under test for both catastrophic failure (e.g. missing component) and quality defects (e.g. fillet size or shape or component skew).
What is Automated Optical Inspection (AOI)?
Automated optical inspection (AOI) is a machine-based technique used to test and check PCB for potential errors, such as surface defects, dimensional defects, as well as component placement defects. As the circuit board is more and more complicated, it’s hard and impossible to manually check the boards, needless to say, AOI plays an important role in checking the printed circuit board after assembly. What’s more, it does make a great effect on getting the necessary product quality in the production line with low cost.
Shenzhen Yideyi Technology Co., Ltd offers complete Electronic System Design and Manufacturing Services from Concept to Realization.From fast-growing, highly competitive niche consumer markets to specialized industrial applications,
FAQ:
Q1. How can we ensure our information should not let third party to see our design?
We are willing to sign NDA effect by customer side local law and promising to keep customers date in high confidential level in all projects.
Q2. What service do you have?
We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other value-added service.
Q3. Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:Surface finish:
Solder mask color:
Silkscreen color:
Q4. MOQ?
We are able to handle Small as well as large volume production with flexibility.
Q5. With payment terms do we accept?
For sample order or small batch, we suggest you to use Pay-pal and Western Union.For mass production batch, we suggest you to use T/T.
Q6. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
Q7. What are the main products of your PCB/PCBA service?
Automotive, medical, Industrial control, Internet of Things, Smart home, military, Aerospace.
