Surface Mount Double Sided PCB Assembly Milling HAL Finishing
HAL Finishing Multilayer Electronic 4 Layer Double Sided PCB Assembly
Main Services:
* Electronic design and technical management of the project.
* Commercial management of the project.
* Implementation of the firmware, IT management and programming.
* Mechanical design,including design realization and 3D models.
* PCBA engineering reserve
PCB capability:
| Item | CAPABILITIES |
| Lead Time | 24 hours expedited service can be offered. 3- 4 days normally for PCBA prototype orders. We will give you accurate lead time when we quote for you. |
| PCB Spec. Requirements | Max. board size: 500mm X 400mm |
| Board Type: Rigid PCBs, Flexible PCB, metal core PCBs | |
| Surface finish: lead/lead-free HASL, immersion gold etc | |
| Assembly Types | Surface mount |
| Through-hole | |
| Mixed technology (SMT & Thru-hole) | |
| Component Sourcing | Full turnkey (All components sourced by PCBGOGO) |
| Partial turnkey | |
| Kitted/Consigned | |
| BGA 0.25mm pitch with X-ray testing | |
| Component Types | Passive components |
| Hard metric connectors | |
| Cable & Wire | |
| SMT Parts Presentation | Cut tape/Partial reel/Tube/Tray/Laser-cut stainless steel |
| Cable Assembly | We supply custom cables, cable assemblies, wiring looms/harnesses and power leads for various industries including automotive, security, mining, medical and entertainment. |
| Stencils | Stencil with or without frame (offered free by PCBGOGO) |
| Quality Inspection | Visual inspection; AOI checking; BGA placement – X-RAY checking |
| After-sale Service |
Repair and rework service will be offered if it is defective or damaged on delivery process.
|
What are vias in double sided PCB?
A via is used to make an electrical connection between the layers of a Multi-Layer PCB. Connecting multiple layers of the board make it possible to reduce the size of the PCB. A via is constructed by placing copper pads on each layer of the PCB and drilling a hole through them.
Shenzhen Yideyi Technology Co., Ltd industrial designers can help you develop the concepts for manufactured products. The projects include not only development of style and appearance of a custom-made enclosure, but also its structural design and manufacturability analysis. We prepare documentation for each device’s subsequent mass-production.
FAQ:
Q1. How can we ensure our information should not let third party to see our design?
We are willing to sign NDA effect by customer side local law and promising to keep customers date in high confidential level in all projects.
Q2. What service do you have?
We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other value-added service.
Q3. Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:Surface finish:
Solder mask color:
Silkscreen color:
Q4. How about your factory production capacity?
we can provide 30000 square meter/month.
Q5. With payment terms do we accept?
For sample order or small batch, we suggest you to use Pay-pal and Western Union.For mass production batch, we suggest you to use T/T.
Q6. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
Q7. What are the main products of your PCB/PCBA service?
Automotive, medical, Industrial control, Internet of Things, Smart home, military, Aerospace.
