Hermetic Maneurop Refrigeration Compressor R407c 460V MTZ125HU
Price:
negotiate
MOQ:
6pcs
Delivery Time:
4-6 weeks
Brand:
Maneurop
Product Description
Model MTZ125HU France Brand Danfosss Maneurop Refrigeration Compressor
Manrurop compressors are made in France, world-wide brand.
Maneurop compressors are specially designed for applications with a wide range of operating conditions. All components are high quality and precision in order to assure a long product life.
Maneurop MTZ and MT series compressors are of the hermetic reciprocaing type and are designed for medium and high evaporating temperature applications.
Technical Specifications
| Compressor model | Displacement | Cyl. number | Oil Charge | Net weight | ||
| Code | in3/rev | cfh at 3600 rpm | oz | lbs | ||
| MT/MTZ018 | JA | 1.84 | 231 | 1 | 32 | 46 |
| MT/MTZ022 | JC | 2.33 | 291 | 1 | 32 | 46 |
| MT/MTZ028 | JE | 2.93 | 367 | 1 | 32 | 51 |
| MT/MTZ032 | JF | 3.29 | 411 | 1 | 32 | 53 |
| MT/MTZ036 | JG | 3.69 | 461 | 1 | 32 | 55 |
| MT/MTZ040 | JH | 4.14 | 518 | 1 | 32 | 57 |
| MT/MTZ044 | HJ | 4.65 | 581 | 2 | 61 | 77 |
| MT/MTZ045 | HJ | 4.65 | 581 | 2 | 61 | 77 |
| MT/MTZ050 | HK | 5.23 | 653 | 2 | 61 | 77 |
| MT/MTZ051 | HK | 5.23 | 653 | 2 | 61 | 77 |
| MT/MTZ056 | HL | 5.87 | 733 | 2 | 61 | 82 |
| MT/MTZ057 | HL | 5.87 | 733 | 2 | 61 | 82 |
| MT/MTZ064 | HM | 6.57 | 822 | 2 | 61 | 82 |
| MT/MTZ065 | HM | 6.57 | 822 | 2 | 61 | 82 |
| MT/MTZ072 | HN | 7.38 | 922 | 2 | 61 | 88 |
| MT/MTZ073 | HN | 7.38 | 922 | 2 | 61 | 88 |
| MT/MTZ080 | HP | 8.29 | 1036 | 2 | 61 | 88 |
| MT/MTZ081 | HP | 8.29 | 1036 | 2 | 61 | 88 |
| MT/MTZ100 | HM | 10.45 | 1306 | 4 | 132 | 132 |
| MT/MTZ125 | HU | 13.15 | 1643 | 4 | 132 | 141 |
| MT/MTZ144 | HV | 14.76 | 1845 | 4 | 132 | 148 |
| MT/MTZ160 | HW | 16.57 | 2071 | 4 | 132 | 152 |
Features
1. The compressor design allows for the motor to be 100% suction-gas cooled.
2. The MTZ series is specifically designed for use with the HFC refrigerants R-407C, R-134a, R-404A, and R-507A, using 160PZ polyester oil as lubricant.
3. Maneurop MTZ compressors can be used in new installations.
4. Maneurop MT and MTZ compressors have a large internal free volume that protects against the risk of liquid hammering when liquid refrigerant enters the compressor.
5. Maneurop MT and MTZ compressors are fully suction-gas cooled. This means that no additional compressor cooling is required and allows the compressors to be insulated with acoustic jackets to obtain lower sound levels, without the risk of the compressor overheating.
Compressor Model Designation- Code numbers (for ordering)
Compressor Reference (indicated on the compressor nameplate)
Approvals and certificates
| CE(European Directive) | All models |
| UL (Underwriters Laboratories) |
All 60 Hz models |
| CCC (China Compulsory Product Certification) |
Depending on the model and motor voltage code. |
