3.7V 2500mAh Rechargeable Polymer Li Ion Battery 505573 5.0*55.0*73.0mm
3.7V 2500mAh Rechargeable Lithium Ion Polymer Battery 505573, Li-Polymer Battery For Toys, Power Tools
Production Description:
AMT is a professional manufacturer engaging in research, development, production, marketing and service of lithium ion pouch battery cell, battery pack and battery management system.LiFePO4 and LiCoO2 are the major material. We have more 300 types of cells, and could make OEM battery pack from 12V-200V, 10-200Ah, which can be used in electric vehicle, E-bike, UPS, energy storage system, telecommunication base station,E-scooter, E-tools, unmanned airplane, golf cart, fork lift, cleaning car, electric wheelchair etc.
1. Basic Parameters
|
Item
|
Pack
|
Remark
|
|
Nominal Capacity
|
≥2500mAh
|
Fully Discharge to3.0V @ 0.2C.after standard charge
|
|
Nominal Voltage
|
3.7V
|
verge Discharge Voltage(discharged at 1CmA)(discharged at 1CmA)
|
|
Resistance
|
cell
|
≤60mΩ
|
|
Battery pack
|
≤170mΩ
|
|
|
Max. Constant Discharge Current
|
2500mA
|
1C
|
|
Charging Cut-off Voltage
|
4.20V(PCM)
|
|
|
Size
|
cell
|
5.0*55.0*73.0mm
|
|
Battery pack
|
5.0*55.5*75.0mm
|
|
|
Range Of Work Temperature
|
Charge
|
0~+45℃
|
|
Discharge
|
-20~60℃
|
2. Features
- With short-circuit production function, safe and reliable.
- Good consistency, low self discharge.
- Light weight, small and customized size.
- Wide application for electronics and industry.
3. Partial Cell Model
|
AMTLithium Polymer Battery, Support Customized
|
||||
|
Model
|
Voltage
|
Capacity(mah)
|
T*W*H(mm)
|
Discharge rate
|
|
902030
|
3.7V
|
500
|
9*20*30
|
1C
|
|
902527
|
3.7V
|
550
|
9.3*25*27
|
1C
|
|
503040
|
3.7V
|
600
|
5*30*40
|
1C
|
|
702050
|
3.7V
|
700
|
7*20*50
|
1C
|
|
532362
|
3.7V
|
720
|
5.3*23*62
|
1C
|
|
363957
|
3.7V
|
800
|
3.6*39*57
|
5C
|
|
503448
|
3.7V
|
950
|
5.2*34*48
|
1C
|
|
523450
|
3.7V
|
1000
|
5.2*34*50
|
1C
|
|
602080
|
3.7V
|
1000
|
6*20*80
|
1C
|
|
603045
|
3.7V
|
1000
|
6*30*45
|
1C
|
|
752550
|
3.7V
|
1000
|
7.5*25*50
|
1C
|
|
922444
|
3.7V
|
1000
|
9.2*24*44
|
1C
|
|
803043
|
3.7V
|
1100
|
8*30*43
|
1C
|
|
103040
|
3.7V
|
1200
|
10*30*40
|
1C
|
|
375256
|
3.7V
|
1200
|
3.7*52*56
|
1C
|
|
883450
|
3.7V
|
1800
|
8.8*34*50
|
1C
|
|
113054
|
3.7V
|
2000
|
11*30.3*54.8
|
5C
|
4. Our Advantages
5. Application
6. Package and Delivery
