18650 26650 12V 8Ah LiFePO4 Lithium Battery Replacement For Lead Acid 150*65*95mm
Price:
Negotiate
MOQ:
1 pcs
Delivery Time:
4-5weeks for samples; 6~7weeks for mass production.
Brand:
ODM/OEM
Product Description
12V 8Ah LiFePO4 Lithium Ion Battery for Lead Acid Replacement Battery Prismatic Battery Pack for Electric Vehicles
18650 cell with high energy density,made on the safe LiFePO4 technology,capacity 2500mAh,Nominal voltage 3.2V,and the operational voltage is 2.8-3.65V.This deep cycle life LiFePO4 cell 3.2v 280ah with high capacity is ideal for Solar energy storage system, UPS, EV, Electric Boat, Electric truck/ forklift, Golf cart, AGV and so on. It is also the best choice for replacing lead-acid batteries.
1. Battery Parameter:
| AMT BATTERY | |||
| 18650/3S Li-ion Battery Pack 11.1V 8Ah / 26650 12.8V 4S 8Ah LFP battery | |||
| Model:UB-L03S009-082 | |||
| Item | Specification | Remark | |
| Nominal capacity | 8Ah | Cell: 18650-2500mAh | |
| Nominal voltage | 11.1V | 3.7V / 1Cell | |
| Charging voltage | 12.6V±0.05V | 4.2V / 1Cell | |
| Charging method | CC/CV | (Constant-current and -Voltage with Limited current | |
| Standard charging time | 0.2C/5hour,0.5C/2hour | Battery capacity÷charging current×1.5 | |
| charging current | 0.5C | 0 ~ +40ºC | |
| Maximum charging current | 1C | 0 ~ +40ºC | |
| Continuous discharge current | 1C | -20 ~ +60ºC | |
| Discharge cutoff voltage | 7.5V | 2.5V / 1Cell | |
| Short circuit protection | Exterior short circuit | Automatic recovery | |
| Internal resistance | ≤200mΩ | AC Impedance 1kHz | |
| Cycle life | ≥500 | ||
| Operating temperature | Standard Charge | 0 ~ +40ºC | |
| Standard Discharge | -20 ~ +60ºC | ||
| Outline dimension | L150*W65*T95mm | Length x wide x height | |
| Protection Circuit Module:PCM-B03S10-188 | |||
| Maximal continuous charging current | 10A | ||
| Maximal continuous Discharging current | 10A | ||
| Over-charge detection voltage | 4.35 V ±0.025V | single cell | |
| Over-charge release voltage | 4.05±0.05V | single cell | |
| Over-charge detection delay time | 0.7S-1.3S | single cell | |
| Over-discharge detection voltage | 2.50V±0.062V | single cell | |
| Over-discharge release Voltage | 3.0±0.10V | single cell | |
| Over-discharge detection delay time | 89-167mS | single cell | |
| Over-current detection | 30±5A | can adjust | |
| Over-current delay time | 6.7ms-13.9ms | ||
2. Related Products:
3. Application:
- Electric Vehicles / Electric Mobility
- Solar / Wind Energy Storage System
- UPS / Backup Power
- Telecommunication
- Medical Equipment
- Lighting
4. Package and Shiping
