3.2V 100Ah Aluminum Case Lifepo4 Prismatic Battery Deep Cycle 36130290 100PF For EV
Deep Cycle 3.2V 100Ah Blue Prismatic Aluminum Case Battery Lifepo4 Battery 36130290-100PF For EV.
The LiFePO4 Lithium-ion Prismatic Battery Cell 3.2V 50Ah 60Ah 100Ah Solar Battery could be assembled into different modules and packs. And we also make packs based on customer requirements, such as 12V-60Ah,16V-120Ah,48V-12Ah,48V-60Ah etc,Especially 48v lithium car battery for electric sweeper. Those packs could be used in e-car,e-bus,e-bike and energy storage system.
Production Description:
1. Our Advantages:
-
lithium iron phosphate power battery has the characteristics of fast charging.
-
High energy storage,ultra low impedance,ultra high energy ratio and energy storage efficiency.
-
More environmentally friendly,more stable and more efficient.
-
High Safely Performance.
-
Advanced Equipment.
-
Competent R&D Team.
-
Stronger national support
2. Key Parameter for cell
|
Items
|
Parameter
|
|
|
Battery Type
|
LiFePO4
|
|
|
Nominal Capacity
|
100Ah
|
|
|
Nominal Voltage
|
3.2V
|
|
|
Internal Impedance
|
≤1mΩ
|
|
|
Standard Charging Mode
|
0.5C CC/CV
|
|
|
Cell Weight
|
≤3kg
|
|
|
End of Charging Voltage
|
3.65V
|
|
|
End of Discharging Voltage
|
2.2V
|
|
|
Max Pulse Discharge Current
|
500A
|
|
|
Max Continuous Discharge Current
|
200A
|
|
|
Max Pulse Charge Current
|
100A
|
|
|
Standard Charge Current
|
50A
|
|
|
Cycle Life
|
≥4000 cycles (80%DOD)
|
|
|
Operating Temperature Range
|
Charging Temperature
|
0～50℃
|
|
Discharging Temperature
|
-20～50℃
|
|
|
Storage Temperature
|
-10～45℃
|
|
|
Appearance
|
Without break, scratch, distortion, contamination, leakage and so on
|
|
|
Application
|
backup power,energy storage,EV,mine locomotive,PHEV etc.
|
|
3. Related Products:
4. Application:
- Various Portable Devices,Such as N/PC/DSC/DVC.
- Cellular Phone,Note PC etc.
- Solar system/Home Energy Power Supply.
- in Electric Bicycle, Electric vehicle, Electric Tricycle, Electric scooter, Electric golf trolley, Electric car, Electric wheelchairs,two wheel vehicles and etc.
5. Package and Shipping
