500Wh Portable Backup Power Station
Price:
Negotiate
MOQ:
100 pcs
Delivery Time:
3-4weeks for samples; 5~6 weeks for mass production.
Brand:
ODM/OEM
Product Description
Portable 500Wh Outdoor Backup Portable Generator Solar with Wireless Charging
1. Product Features:
- With built-in pure-sine wave inverter, which means it produces an output that is exactly the same as supplied by an AC wall outlet.
- Highly compacted design with e-vehicle lithium-ion battery pack, portable and powerful.
- User friendly, smart processor controller indiated on LED display.
- Safety priority, built-in BMS and protection circuit.
- Support 3 ways to recharge, AC 110~240V charging, Car charging, Solar Power charging(MPPT).
- Long service life 48+months.
- Provide AC output and DC output two different output modes to match the demand of different electronic products.
- Apply USB 5V, DC 12V and AC Power to home appliance(less than rated power 520Wh) and portable electronics.
- The portable solar power generator DY63 can be used as both on-line UPS power supply and outdoor emergency standby power supply.
2. Main Parameter:
| Model | AMT500W | |
| Battery Pack | Battery Cell | Lithium-ion Grade A battery cells |
| Capacity | 520Wh) | |
| Cycle Life | >800 cycles | |
| BMS(Battery Management System) | Multiple Safety Protection: over-load, over-voltage, over-current, over-temperature, short circuit. | |
| DC Output | USB/USB QC3.0 | 2*5V2.4A; 1*QC3.0 5~12V 18W(max.) |
| Type-C USB | 1*Type C PD3.0 5~20V 60W(max.) | |
| 12V DC | 2*12V/5A(DC5.5x2.1mm); 1*12V/12A(Cigar lighter) | |
| Efficiency | >93% at 70% of full loading | |
| AC Output | Rated Output Voltage | 100~240V(Customized according to different countries and regions) |
| (Inverter) | Output Frequency | 60Hz/50Hz(Depends on factory setting according to different countries and regions) |
| Output Voltage Type | Modified Pure Sine Wave | |
| Output Soket | Customized according to different countries and regions | |
| Output Power | 500W | |
| Output Peak Power | 600W (5seconds) | |
| Efficiency | >90% at 70% of full loading | |
| Input | AC Charge | AC-DC Adaptor(CC/CV) 100W, (DC5.5x2.1mm) |
| (Recharge) | PV/Solar Charge | MPPT, Input voltage range:14~40V, 60W, (DC5.5x2.1mm) |
| Car Charge | Car input voltage range:13-40V, Charge current:10A max | |
| (DC5.5x2.1mm or Cigar lighter port) | ||
| Display | Battery Status | Digital battery capacity, battery image flashing while charging |
| Working Status | Discharging, Recharging, | |
| Output/Input Power Consumption | Digital data according to real-time powered electrical appliance. | |
| Working Condition | Charge Temperature | 0ºC~45ºC |
| Discharge Temperature | -10ºC~60ºC | |
| Operation Humidity | 10%~90% | |
| LED Lighting | Power | 5~10W(4modes of low bright, high bright, SOS, flash) |
| Heat Dissipation | Air cooling, Aluminum housing. | |
| IP rate | To prevent the spraying water from vertical direction angle less than 60 degrees. | |
| Self-consumption | <100uA(turn-off) | |
| Dimensions & Weight | 196*108*126mm | |
| Certificates | PSE,CE ,FCC, RoHS,UN38.3 | |
3. Our Advantages:
- More power less weight
- Faster solar charging
- Pure sine wave inverter
4. Product Application
5. Safety Guarantee
