LFP 72V 30Ah 4P20S RV Li Ion Battery Pack For Electric Motorcycle
Price:
Negotiate
MOQ:
1 pcs
Delivery Time:
4-5weeks for samples; 6~7weeks for mass production.
Brand:
ODM/OEM
Product Description
72V 30Ah Lithium LiFePO4 Battery Pack for Electric Motorcycle
- Outlook: Simple and smooth surface, can be easily cleaned.
- Light-weight: Light weight design, packed by aluminum plate and plastic components.
- Module design: Reasonable capacity(3.6v 72.8ah/80ah/100ah,etc), can be assembled to different voltage.
- Structure: Stable hollow structure, protecting the lithium pouch cell well.
- Insulation: Perfect electrical insulation, both inside and outside.
- Performance: Good heat conductivity, safety performance.
1. Cell specification: LFP(LiFePo4) and NMC(LiNiCoMnO2) cell:
|
Model NO.
|
Capacity
|
Voltage
|
Dimension(mm)
|
Weight
|
Discharge & Charge
|
|
F9088178
|
12.5Ah
|
3.2V
|
9.0*88.5*179.5
|
280±5.0g
|
37.5&12.5 A
|
|
N8088178
|
12.5Ah
|
3.6V
|
8.0*88.5*179.5
|
260±5.0g
|
37.5&12.5 A
|
|
N43188236
|
20Ah
|
3.6V
|
4.3*188.5*236.5
|
400±5.0g
|
60&20 A
|
|
N7892232
|
18.2Ah
|
3.6V
|
78*92*232
|
360±5.0g
|
54.6&18.2 A
|
|
F90137232
|
25Ah
|
3.2V
|
9.0*137.5*232.5
|
550±5.0g
|
75&25 A
|
|
F90160227
|
30Ah
|
3.2V
|
9.0*160.5*228.5
|
640±5.0g
|
90&30 A
|
|
F95145265
|
33Ah
|
3.2V
|
9.5*145.5*266.5
|
700±5.0g
|
99&33 A
|
|
T85188286
|
40Ah
|
3.6V
|
8.5*188.5*236.5
|
790±5.0g
|
120&40 A
|
2. Battery Parameter:
| N0 | Item | Specification | Notes |
| 1 | Cell Type | 8865190 | |
| 2 | Array Mode | 4P20S | |
| 3 | Nominal Capacity | 40Ah at23±2ºC | Standard charge and discharge |
| 4 | Nominal Voltage | 72V | |
| 5 | Energy | 2880Wh at23±2ºC | |
| 6 | AC Impedance | ≤70mΩ | At 1kHz with 100%SOC |
| 7 | Charging Voltage | 84±0.15V | |
| 8 | Discharge End Voltage | 60.0±0.3V | |
| 9 | Standard Charging Method | CC and CCV is 20A | Tempeature23±2ºC,charge end with 2.5h orcurrent drops to 0.02, |
| 10 | Max.Charge Current | 40A | Temperature23±2ºC |
| 11 | Standard Discharging Method | 40A | Constant Current Discharge with 1C |
| 12 | Max.Discharge Current | 60A | Discharge Time: Less than 60 s(at23±2ºC) |
3. Product Features:
- High energy density
lifepo4 battery cell LiNiCoMn battery cell (ab.NCM battery)
weight energy density 150wh/kg 200wh/kg
volume energy density 280wh/L 334wh/L
- Low internal resistance:Methods of reducing the internal resistance:
**Using carbon coated aluminum foil
**Multiple electrode tab design
**Increasing the width of electrode tab
**Coating PVDF on battery separator
**Pore-creating artificially3.Application
4. Application:
5. Package and Shiping
