3.2V 20Ah 25Ah 37Ah 50Ah LiFePO4 Battery Cell For Energy Storage
Price:
Negotiate
MOQ:
1 pcs
Delivery Time:
4-5weeks for samples; 6~7weeks for mass production.
Brand:
ODM/OEM
Product Description
Large Capacity 3.2V 20Ah 25Ah 37Ah 50Ah LiFePO4 battery cell for Energy Storage EV Car / Energy Power Supply
1. Features for 3.2V 20Ah Battery cell:
- Excellent stability based on the proprietary separator technology.
- Lightweight pouch that generates little heat.
- Secured competitiveness in the materials through raw material.
- Development and independent production.
2. Product Specification:
|
Items
|
Description
|
Dimension
|
|
T
|
Thickness
|
8mm Max. (Before shipment)
|
|
W
|
Width
|
156mm Max.
|
|
L
|
Length
|
241mm Max.
|
|
A
|
Sealant length
|
0.5-2.5mm
|
|
B
|
Tab width
|
40.0±1mm
|
|
|
Tab thickness
|
0.30±0.01mm
|
|
C
|
Top sealing width
|
16.0±0.5mm
|
|
L1
|
Tab distance between edge
|
19.0±2.0mm
|
|
L2
|
Tab length
|
20.0±1.0mm
|
|
W2
|
Pocket outer width
|
153±0.5mm
|
|
L3
|
Pocket outer length
|
218±0.5mm
|
|
W1
|
Two tab distance
|
78.0±1.5mm
|
|
L4
|
Nickle plated brass length
|
6.0±1.0mm
|
3. The Advantages for 3.2V20Ah Battery Cell
- Overcharge and overdischarge protection, multiple battery protection, extend service life.
- Explosion proof and leak proof liquid, safely exhaust, quickly take out waste water, avoid expansion.
- Recyclable charging, green energy-saving, economic and durable, explosion-proof and leak proof liquid, more reliable use.
- With stable performance and small internal resistance, it is the best choice for battery pack and automobile battery.
4. Application
5. Package and Shipping
- Cartons or designed according to customer needs
- Can be sent by air or by sea
