ISO9001 A1 4.5mm Color Coated Aluminium Sheet Environmental Protection

Price Negotiable

Price: 45USD-55USD

MOQ: Negotiable

Delivery Time: 7-15work days

Brand: WHOLETOPS

Product Description

Environmental Protection Energy-saving Ceramic Coated Aluminum Panel

Product Overview:

Material	Aluminum	Aluminum Alloy	1100 / 3003 / 5005
Total Thickness	2.0mm——4.5mm (normal), special thickness can be customized.	Surface Finish	Ceramic Coated
Class Fire Prevention	A1	Warranty	10-20 years
Size	150~3000mm×150~6000mm, Special size can be customized.	Color	Customized
Packing	Wooden Box	MOQ	500㎡

Product Information:

WHOLETOPS brand Environmental Protection Energy-saving Ceramic Coated Aluminum Panel is made of Aluminum alloy 1100 / 3003 / 5005 series (aluminum sheet), As a kind of curtain wall, used for wall protection and non-lighting walls, instead of mosaic and general sandblasting facade. With its light texture, good strength characteristics in the use of high-rise buildings have advantages, due to various loads at high-rise buildings all the time, especially by the wind pressure, mosaic Easy to fall off, because of the large wind pressure and deformation. aluminum panel based on its unique advantages and can be used in high building widely.

Specification:

1. Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm, 5.0mm, 6.0mm, 7.0mm, 8.0mm and so on.

2. Surface finish: PVDF coated / Power coated

3. Aluminum Alloy: 1100, 3003, 5005

Scopes of Application:

Interior or exterior wall panel for all public buildings such as airport,railway station,hospital,shopping mall,etc.
All kinds of column cover and corner cladding.
Indoor ceiling for decoration.

Product advantages:

1. High hardness and scratch resistance; its hardness ≥ 7H, is 7 times compare with the fluorocarbon (PVDF) coated hardness

2. Silicate ceramic aluminum panel is use water as the solvent, not including xylene, it is safe and green product

3. At 300 degree, the color will not change and coating will not damaged. At 600 degrees, The coating film only occur discoloration without decomposition, It belonging to the incombustible decorative material, fire rating of A1 (fluorocarbon sheet A2)

4. Inorganic material to eliminate static electricity, so that the pollutants in the atmosphere will not adhesion, always keep the gorgeous appearance, It has the self-cleaning function

5. Can provide a variety of color, can adjust the brightness in a certain range, to meet the different requirements for the color and luster of buildings, to the designer to provide more vast space

Compare with PVDF coated solid aluminum panel:

Item	PVDF coated	Ceramic paint
Fire proof grade	A2 grade(smoke)	A1 grade(no smoke)
Hardness	0~2H	7~9H
Scratch resistant	Easy to scratch	Not easy to scratch
High temperature resistant	280℃ have smoke	1600 ℃ no smoke
QBWear resistant standard	＜500 time	＞2000 time
Toxicity	Organic solvent	water
cleaning	not self-clean	Self - clean
life	15 years	30 years
