Medical Care Supply Closed Suction Catheter Double Swivel Elbow-Automitic Flushing 72H
This is a closed suction catheter system designed for 24-hour or 72-hour use, commonly used in ICU settings for mechanically ventilated patients. It allows tracheal suctioning without disconnecting the ventilator circuit, reducing the risk of cross-contamination and VAP (Ventilator-Associated Pneumonia).
✅ Features:
*Double Swivel Elbow: Provides flexibility and reduces tension on the ventilator circuit.
*Automatic Flushing: Helps clean the catheter after use, reducing manual intervention.
*72-Hour Usage: Designed for extended use, minimizing the need for frequent catheter changes.
*Protective Sleeve: Isolates the catheter to prevent infection.
*Soft Suction Tip: Minimizes trauma to the tracheal mucosa.
*Push Switch & Luer Lock: Allows for easy control and irrigation.
Optional Specification:
| Product Code | Size | Colour Code | Tube OD(mm) | Length of Tube(mm) | |
| MC-07210 | Adult/72H/Endotracheal | Bla ck | Black | 10Fr(3035mm) | 600mm |
| MC-07211 | Adult/72H/Endotracheal | Whi t e | White | 12Fr(4.05mm) | 600mm |
| MC-07212 | Adult/72H/Endotracheal | Gre en | Green | 14Fr(4.75mm) | 600mm |
| MC-07213 | Adult/72H/Endotracheal | Orange | Orange | 16Fr(5.45mm) | 600mm |
| MC-07200 | Adult/72H/Endotracheal | Bla ck | Black | 10Fr(3.35mm) | 300mm |
| MC-07201 | Adult/72H/Endotracheal | Whit e | White | 12Fr(4.05mm) | 300mm |
| MC-07202 | Adult/72H/Endotracheal | Gre en | Green | 14Fr(4.75mm) | 300mm |
| MC-07203 | Adult/72H/Endotracheal | Orange | Orange | 16Fr(5.45mm) | 300mm |
-Instructions for Use *Set up Procedure
1. Inspect the product before use. Do not use it if the package is not intact.
2. Open the sealed package and remove the product.
3. Connect the Endotracheal Tube/Tracheostomy Tube to the Revolvable adapter.
4. Connect ventilator tube to the Revolvable Ventilator Connector.
5. Attach the date label to the color ring.
6. Before suctioning commences, ensure that the cap of the MDI Port and Irrigation Port is closed.
7. Before suctioning: Please ensure that the on-off valve is in the open position. Simply slide the on-off valve to a position which allows the catheter to enter the Endotracheal tube/Tracheostomy tube.
*Suctioning Procedure Caution-always use the recommended vacuum levels./Consider length of suctioning time
1. Grip the three-way adaptor in one hand and use the other hand to feed the suction catheter into the Endotracheal tube/Tracheostomy tube to the required depth. Depth markers can be visible through the protective cover for your guidance.
2. Once the suction catheter is in the desired position /depth depress the vacuum control valve to apply suction.
3. Remove the suction catheter until the protective sleeve is straight. 4. Repeat steps1-3 as necessary.
Services:
We offer OEM and ODM services, customizing product specifications, packaging, and branding to meet customer requirements. We also offer sample services to help customers evaluate product quality before placing large orders.
The company also provides technical support and after-sales consulting to ensure customers use their products correctly and answer any questions. Its professional services span the entire process, from pre-sales consultation and order processing to production quality control, logistics and shipping, and after-sales support, striving to build long-term customer partnerships.
