35mm Micro Brushed Permanent Magnet DC Motor 5000rpm Low Voltage For Bladeless Fan
Price:
Negotiated The Price
MOQ:
200
Delivery Time:
7-12 working days
Brand:
SECORE
Product Description
35mm Micro NdFeB Magnet Brush Motor Customized High Speed High Power Dc Motor
Secore brush dc motor DC3540
- Rated voltage: DC 12V /24V
- The direction of rotation: CW/CCW
- No-load speed: 6000 rpm
- No-load current: 0.03A
| Model | VOLTAGE | NO LOAD | WITH LOAD | STALL | |||||||
| SPEED RPM |
CURRENT max A |
SPEED RPM |
TORQUE kg.cm mN.m oz.in |
CURRENT max A |
Output W |
TORQUE g.cm |
CURRENT max A |
||||
| DC3540 | 12 | 6200 | 0.07 | 5000 | 0.071 | 6.958 | 0.986 | 0.39 | 3.6 | 0.285 | 1.92 |
| DC3540 | 24 | 6200 | 0.04 | 5000 | 0.082 | 8.036 | 1.1389 | 0.25 | 4.1 | 0.364 | 0.91 |
Low voltage permanent magnet DC motor applies for bladeless fan, office automation equipment, precision instrument, kids toys,electric water valves, robots, financial equipment, audio and visual equipment, industrial automation and secure, banking and vending system, home and office automation, automatic door system, medical device, personal care, power tool, smart household appliances, kitchen appliances, auto parts, RC Drone, Fascia Massague Gun
Mounting sizes:
